Dynamic IR Camera Face Recognition Thermometers Access Control Terminal
Dynamic IR Camera Face Recognition Thermometers Access Control Terminal
Specifications
Brand Name :
CSXT
Model Number :
CSXT-FR2
Certification :
CE ROHS
Place of Origin :
Guangdong, China
MOQ :
1-49 Pieces
Price :
$380.00
Supply Ability :
100+PCS+5days
Packaging Details :
L400*W320*H280 mm
Resolution :
1280 x 960, 1280*800
Special Features :
Motion Detection, Night Vision, Time & Attendance
Data Storage Options :
Cloud
Function :
Face Detection with thousand local face database
Product Name :
face recognition temperature measurement terminal
Type :
For semi-outdoor or pure outdoor use
Camera :
4.0mm RGB + IR
Application :
Security Access Control Management
Communication :
USB
Color :
Silver+Black
Certificate :
CE FCC ROHS
Warranty :
2 Years
Selling Units :
Single item
Single package size  :
38X13.5X8.5 cm
Single gross weight :
1.700 kg
Package Type :
We will pack: 1. Wrap each item separately 2. Use a strong box 3. Create a double wall at the bottom of the box 4. Cushion your items well 5. Create another cardboard double wall on top 6. Close the parcel carefully 7. Seal the parcel with st
Description

Dynamic IR Camera Face Recognition Thermometers Access Control Terminal

8 Inch Face Recognition Door Access Control Terminal Dynamic Ir Camera Facial Recognition Temperature Measurement Machine

Face Recognition Device Body Temperature measurement Thermal Camera visitor management system

(8-inch ultra-thin) (Model No:CSXT-FR2)

Product Advantage:

Our own developed face tracking exposure algorithm(linear mode), WDR≥110DB

Own patent protected file storage system (Linux's original file system) used all glass material aspheric lens adopted own top-class face recogntion algorithm

Stable quality control, all electronic components choosed from first-line suppliers, such as Samsung brand memory and Flash

Hardware&software Customerized service, protect customer own design and confidential data

In addition, We provide face recognition SDK for secondary development, making it easier for partners who are professional at face recognition algorithm and Face search APP design. Our self-developed face recognition platform (FaceGateMngPlatform ) is also available for partners who lack good enough development capabilities

Product Features

1. Support external HDMI large screen;

2. Support external ID card / RFID reader;

3. Support serial port input and output, support Wiegand output, output content supports configuration;

4. Support the RFID card , can also achieve the integration of human cards;

5. Dynamic face detection based on video stream and tracking recognition algorithm are adopted;

6. Support to store 30, 000 face photos, 5 million recognition records;

7. The accuracy rate of 1: N recognition is high (99.7% under 97% pass rate).

8. Recognition speed is fast, face tracking and detection takes about 20ms time, facial feature extraction takes about 500ms, and face comparison takes about 0.1ms.

9. Support stranger detection, stranger level can be configured;

10. Support face recognition or stranger detection of the scene of the photo preservation;

11. Support interface docking;

12. Support customization;

13. Support screen display content configuration;

14. Support identification distance configuration

Product Specification

Hardware
Processor Sextuple processor + 2G memory + 8G flash
Operating system Linux Operating system
Storage Support TF card storage
Camera module U21R
Sensor 1/2.8" Progressive Scan CMOS
Lens 6mm(optional)
Performance
Recognition height 0.5-1.5 meters,Angle can be adjusted
Recognition distance 0.5~5 meters,depends on lens
Face angle 30 degrees left and right, 30 degrees up and down
Recognition time Less than 1 second
Function Support 250,000 capture library, real-time capture, support 65,000 list library
Interface
Switch inputs 1ch switch input
Power DV12V/3A
Network Interface 1x RJ45 10M / 100M Adaptive Ethernet port
Wiegand Interface 1ch Wiegand interface input/output
USB interface 1ch USB interface
Camera Data
Camera Two cameras: 1x B/W camera ; 1x color camera
Effective pixels 2MP,1920*1080
Min Illumination Color 0.01Lux @F1.2(ICR);B/W 0.001Lux @F1.2 (ICR)
SNR ≥50db(AGC OFF)
WDR ≥120db
Video Coding H.265 Main Profile /H.264 BP/MP/HP /MJPEG
Resolution Main stream:50Hz: 25fps (1920×1080,1280×720)
60Hz: 30fps (1920×1080,1280×720)
Sub stream:720*576,1-25(30)fps/640*480,1-25(30)fps
320*240,1-25(30)fps

Real Product Photo

Dynamic IR Camera Face Recognition Thermometers Access Control Terminal

Dynamic IR Camera Face Recognition Thermometers Access Control Terminal

Company Information

Dynamic IR Camera Face Recognition Thermometers Access Control Terminal

Dynamic IR Camera Face Recognition Thermometers Access Control Terminal

Dynamic IR Camera Face Recognition Thermometers Access Control Terminal
