Custom Line Laser Diode Module 405nm - 850nm Machine Vision Positioning Contour Scanner
Custom Line Laser Diode Module 405nm - 850nm Machine Vision Positioning Contour Scanner
Custom Line Laser Diode Module 405nm - 850nm Machine Vision Positioning Contour Scanner
Custom Line Laser Diode Module 405nm - 850nm Machine Vision Positioning Contour Scanner
Custom Line Laser Diode Module 405nm - 850nm Machine Vision Positioning Contour Scanner
Custom Line Laser Diode Module 405nm - 850nm Machine Vision Positioning Contour Scanner
Custom Line Laser Diode Module 405nm - 850nm Machine Vision Positioning Contour Scanner
Custom Line Laser Diode Module 405nm - 850nm Machine Vision Positioning Contour Scanner
Specifications
Brand Name :
AIMLASER
Model Number :
AM780U100G2
Certification :
FDA, IEC
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T, Western Union, PayPal
Supply Ability :
1000pcs/month
Delivery Time :
10-20 days
Packaging Details :
Anti-static bag, Carton
Product name :
Powell Lens Well-Distributed Line Laser Module
Wavelength :
780nm
Line Width :
≤50um@150mm
Fan Angle :
90°
Operating Voltage :
3-24V DC
Output Power :
≤100.0mW
Case Material :
Insulation Aluminum Black Anodized
Size :
12x45mm
Driver Mode :
CW, Analog Modulation, Digital Modulation, Computer Control
Life Span :
10,000 Hours
Description

Custom Powell Lens Uniform Line Laser Diode Module 405nm - 850nm Machine Vision Positioning Contour Scanner Laser Source

Product Description

AIMLASER provides customized uniform line laser diode modules with a range of customization options. These modules are equipped with Powell lenses, ensuring well-distributed laser intensity and light.

The thinnest line produced by the uniform line laser modules can reach 10µm, with optional fan angles ranging from 10° to 90° and wavelengths from 405nm to 850nm. Input voltages are available between 3V and 24V DC. These modules feature a compact design, narrow line width, high stability, and reliable performance. They project thin, collimated laser lines and are widely used in machine vision guidance systems, industrial robotics, 3D scanning, medical instruments, and surface defect detection.

The 850nm 100mW uniformly distributed red line laser module subassembly also includes an adjustable focus for added versatility.

Custom Line Laser Diode Module 405nm - 850nm Machine Vision Positioning Contour ScannerCustom Line Laser Diode Module 405nm - 850nm Machine Vision Positioning Contour Scanner

Specifications

ITEMS

PARAMENTERS

Model Number

Powell Lens Uniform Distribution Line Laser Diode Module

Wavelength

850nm

Output Power

≤100.0mW
Output Aperture Φ5.0mm

Line Width

≤50um@150mm

Fan Angle

90°
Input Voltage 3~24.0VDC
Working Current <80mA
Driver Mode CW, TTL, Analog Modulation, Digital Modulation
Dimensions Φ12x45mm
Divergence 0.3mrad

CDRH Class

Class IIIb

Circuit control

Auto Constanct Current (ACC)

Circuit Protection

Static, Surge, and Reverse Polarity Protected

Working Temperature

-10℃ to 50℃

Storage Temperature

-40℃ to 80℃

Optics

Powell Lens

Material

Aluminum Black Anodized (Insulation)

Life Time

≥10,000Hrs

Features

1. Compact size, narrow line width, high stability and reliability.

2. Long Lifetime and Ultra-lower Noise.

3. Using high quality powell lens.

4. Using original Laser Diodes from Arima, Osram, Nicha and branded chips.

5. Conform to ROHS, FDA, IEC, SGS standards.

6. Provide one-year warranty and customized solutions.

Applications

The 850nm 100mW powell lens even engry distribution IR(infrared) line laser diode modules applications:

● Machine Vision System

● 3D Scanning System

● Laser Profilometer

● Laser Measuring Profilometer

● Laser Contour Scanner

● Laser Scribe Positioning Machines

● Machine Visual Products

● Industrial Visual Measurement System

● Machine Vision Cameras

● Industrial Robot Visual Guidance System
● Industrial Smart Cameras ● Automatic Equipment Visual Positioning System

Trade Terms

1) Payment: T/T, PayPal, Western Union, etc.

2) Shipment: FedEx, DHL, UPS etc.

3) Delivery Time: 5 - 20 days.

4) Shipment Terms: FOB Xi'an China

Why Choose Us

A. Over 20 years laser experience.

B. Large-scaled facility 4,500sq.m2 and over 180 professional staffs.

C. Use original LDs from Arima, Osram, Nicha and so on to guarantee reliability.

D. Strictly following ISO9001:2008 quality system.

E. Product conforms to FDA, IEC and GB standard.

F. Strong design and production capabilities, partners of famous brands.
