Unique Driving System 4000 Watt 1800 Rpm Air Cooled Diesel Engine High Speed
Unique Driving System 4000 Watt 1800 Rpm Air Cooled Diesel Engine High Speed
Unique Driving System 4000 Watt 1800 Rpm Air Cooled Diesel Engine High Speed
Unique Driving System 4000 Watt 1800 Rpm Air Cooled Diesel Engine High Speed
Specifications
Brand Name :
KAIAO
Model Number :
KA178FS
Certification :
CE/ISO/SGS
Place of Origin :
China
MOQ :
5 pcs
Price :
Negotiable
Payment Terms :
T/T or L/C
Supply Ability :
20,000 pcs per month
Delivery Time :
10 working days after received down-payment
Packaging Details :
Cartons
Bore x Stroke (mm) :
78x62
name :
Air Cooled Diesel Engine
Fuel Type :
0#, -10#, -20# Diesel
Lube Oil Type :
CD grade or SAE 10W-30, 15W-40
Lube Oil Capacity (L) :
1.1
Net Weight (KGS) :
33
Starting System :
Manual
Rate Power/Max Power(kw) :
4/4.4
Description

Unique Driving System Air Cooled Diesel Engine High Speed 4000 Watt 1800rpm

structure frame type, four small wheel
Rated power 7KW
Maximum power 8KW
Rated frequency 50Hz
Rated voltage 220V
Excitation mode Brush
Fuel tank capacity / working time 12L/5.5 hours
Engine type RZ192FA/E
Engine type single cylinder four stroke air cooling
Bore * stroke 92 * 75
Displacement 498cc
Fuel model summer 0#, winter -10#
Lubricating oil type SAE15W/30
Lubricating oil capacity 1.65L
Starting mode hand pull start / electric start
Battery capacity 20Ah
Unit size 720 x 500 x 630(mm)
Packing size 745 x 520 x 655 (carton)
Net weight / gross weight 96/101

Unique Driving System

Adopted designed precise gear driving & balance shaft system to ensure more excellent performance & stable than other makers

Perfect Direct Injection

To realize the ideal match between the combustion chamber and injection system, keep maximum power from every drop of diesel, it’s extraordinarily low fuel consumption & environmentally friendly engine.

Low Vibration & Low Noise

Vibration & Noise reduction is achieved through the adopt of precision balancers. It makes operation comfort even under long working hours.

Compact Design, Quick & Easy Start

With stronger but lightweight alloy used for main engine parts, extra tough crankshaft and overall compact structure, ensure powerful and simple to install and quick & easy to start.

Application:

KAIAO air-cooled single cylinder engines could be assemble with Agricultural machines (such as Tillers), marine boats, generators & pump sets etc.

Unique Driving System 4000 Watt 1800 Rpm Air Cooled Diesel Engine High Speed

FAQ

Q1.What is your terms of payment?
A:T/T 30% as deposit,and 70% before loading. We will show you the photos of the products and packages before you pay the balance.

Q2.What your terms of delivery?
A:EXW,FOB,CFR,CIF.

Q3.How about your delivery time?
A:Generally,it will take about 20 days after receipt of deposit payment.The specific delivery time depends on the items and the
quantity of your order.

Q4.Are you interested in dealership with local company?
A:Yes,we are quite interested in this business.we'd like to cooperate with some local partner to sell more truck in local market
and supply better service.

Q5.Do you test all your diesel engine before delivery?
A:Yes,we have 100% diesel engine test and complete quality control system defore delivery.

Q6.How do you make our business long-term and good relationship?
A:1.We keep good quality,competitive price and efficient service to ensure our customers benefit;
2.We protect the benefit of dealer or agent,in specifical period and region.
