Satin Color Adjustable Cable Grippers Customized Size For Drop Ceilings
Satin Color Adjustable Cable Grippers Customized Size For Drop Ceilings
Specifications
Brand Name :
YW
Model Number :
YW-86092
Place of Origin :
Dongguan,China
MOQ :
1,000pcs
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
100,000pcs/month
Delivery Time :
10-15 Work Days
Packaging Details :
Export Carton- 35*25*18cm
Material :
Brass
Size :
Φ15*53mm;Customized
For Cable Diameter :
Ø1.0~Ø1.5mm
Thread Size :
No Thread
Finish Color :
Satin/Customized
Cable Exit :
Side Exit
Plunger Diameter :
Ø2.4mm
Others :
OEM/ODM
Description

Ø15mm Adjustable Cable Grippers Brass Material With Satin Color

This Adjustable Cable Gripper is made from brass,plated in Satin color.

Chrome color,as well as Black and White finish is available too.

The size is Φ15*53mm,and can be customized too.

It is suited to indoor applications with diameter wires 1.0~1.5mm,

Contact us for your requirements,or send us your drawing for OEM.

The gripper has a self locking mechanism that saves time and effort when

suspending signs, panels and graphics from a ceiling.

A clutch release button makes levelling up a breeze. The height is adjusted at

the sign rather than at the ceiling - much more convenient!

With our many Cable Gripper styles you can hang anything: Drop Ceilings,

Light Fixture Pendants, Signs, Displays, Shelves, Picture Frames and more.

Description

1. Item Name Φ15mm Adjustable Cable Grippers
2. Material Brass
3. Size Φ15*53mm / Customized
4. Thread Size None Threaded
5. Plunger Diameter Φ2.4mm
6. For use with Cable Ø1.0~Ø1.5mm
7. Finishing Color Satin,or Customized
8. Application

Use for quick and easy suspension of LED Panel Lights and other Lighting products in office,home,etc.
9. Safe Working Load 30KG,depends on the cable diamter work with
10. How It Works

Adjustable Cable Grippers are sophisticated in design but simple to use:

Insert the cable into the plunger and slide the gripper to the desired position.

Where it stops it locks.To re-adjust, simply depress the plunger with your fingertip and move the gripper to a new position. Release the plunger to lock.


The 3--ball gripping mechanism is spring-loaded and allows the gripper to move freely up the cable. It cannot move down unless the plunger is depressed.While there is any weight at all on the gripper, the plunger cannot be depressed.

An optional “safety nut” or “safety cap” can be added to completely lock the mechanism in both directions. The greater the weight, the stronger it grips.

Advantages

The wire grippers have more than the advantages as below:

1. The fastest locking device available for quick and easy suspension,

Supplied in ready-to-use,allows quick installation and instant adjustment;
2. Tool Free:Setting and Adjustable without utilizing tools;
3. Self-Locking:User Friendly and dismountable;
4. Perfect for Suspend Signage + Lighting Systems + Suspended Fixtures;
5. Compact design,easy taking and delivery.

FAQ

Shipping: DHL, UPS, FedEx and TNT Express, Airline and Ocean shipping.

All shipments originated by us will be freight collected,or those charges will be billed to the customer.

It is also possible to ship via Collect or 3rd-Party using your own shipping account.
