Brass Part Three Branch Outlet 15mm Dia Hanging Attachment Hardware YW86269

Application:

1. On a drywall or wood ceiling, simply use an anchor (drywall) or screw to install part one of the connector. Then put the Lock cable through the second part of the connector. The "stop" on the connector will stop the wire from falling out.
2. Screw this second part of the connector to the first part already installed in the ceiling.
3. Now you are ready to install the slider to the wire and hang your light fixtures.

4. These adjustable sign hanger kits can also be used in art installations, in shop window displays as well as in industrial applications such as suspending safety signs.

Feature:

• Cost-effective fitting
• Attractive nickel-plated finish
• Can be fitted easily on-site
• Strong cable fitting

The three legs hanger part is designed for architectural lighting suspensions where aesthetics are important and offers simple one-handed adjustment and a range of feet options to accommodate many types of luminaires.

Easy to use

A.Insert the cable into the gripper. Always insert the cable through the pin unless otherwise stated.

B.Adjust the gripper up. When you let go of the gripper it will automatically lock itself on the cable.

C.Press the pin and adjust down. When you press the pin the lock opens and the gripper slides freely up and down the cable. Release the pin to lock the gripper again.

We provide a wide range of aircraft cable

Aircraft cable is available in galvanized steel and Stainless Steel,

and is also offered in Stainless Steel Type 316.

Our aircraft cable mainly comes in 7x7 strand,

1x7 strand, 1 x19 strand, and 7x19 strand is available too if required

All in galvanized steel or stainless steel.

Aircraft cable sizes range from 1.0mm to 3.0, with different breaking strengths (tensile strengths).

Quality Control

As all manufacturers and installers know, suspending objects safely over people’s heads is their first and most critical responsibility.

Safety is our number one concern. Each and every gripper is a precision-built machine.

Warm tip

The max load-bearing of the according to the cable, please don't use it in the stuff of exceeding weight to avoid danger. If you want to try, Please be careful.
