SANHUAN Steering 77 Passenger Aero Bus With Pneumatic Suspension
SANHUAN Steering 77 Passenger Aero Bus With Pneumatic Suspension
Specifications
Brand Name :
Aero ABus
Model Number :
Aero Bus 13m Length
Certification :
CE/ISO9001:2008/AIRPORT EQUIPMENT CERTIFICATE/SGS
Place of Origin :
China
MOQ :
1 Unit
Supply Ability :
25 Units per month
Delivery Time :
5 months, flexible
Packaging Details :
Nude package to suit for long distance marine transportation
Application :
Airport Grounding Equipment
Standard Passenger Seats :
Customized
Engine :
Cummins
Minimum Turning Radius :
13m
Standing Area :
24m2
Description

Aero Bus World Top 2 Manufacturer Reliable Quality Competitive Price 13m Length

Description:

1. Passenger doors on both sides

2. More mobility and flexibility on the apron

3. Competitive Price

Specification:

No.

Particulars

Specs

1.

Length × Width ×Height

13650mm×2700mm×3178mm

2.

Bus body

Low carbon alloy steel body with aluminum apron;

3.

Wheel base

6670mm

4.

Passenger accommodation capacity

Up to 77 passengers including thirteen (13) seats, in compliance with IATA specifications: four (4) Passengers per sqm

5.

Curb weight

12250kgs

6.

Steering

SANHUAN, 3401ZB3-001H

7.

Rear axle

Specially manufactured high intensity curved axle

8.

Front tire (single tire)

BRIDGESTONE, 12R22.5

9.

Rear tire (twins)

BRIDGESTONE, 9.5R17.5

10.

Pneumatic suspension

GOODYEAR, 270~340mm, 6 nr. pneumatic suspension

Fuel tank volume

(120 + 80)liter

Anti-freeze fluid

20 liter

Engine lubrication system

14.2 litter

Gearbox lubrication system

18 liter

Main reduction gear of front axle and wheel rim reduction gear

10 liter

The varied height from passenger cabin floor sill to the ground level

270mm~340mm subject to embarkation and/or disembarkation of passengers

Minimum turning radius

<13500mm

Engine

4-strok, DEUTZ diesel engine
Emergency system

1. Set the brake system discharge device by following the instruction labeled;

2. The emergency cover on wheel cover should be sealed to prevent from waterproof;
