Inner Fan for 300 Cubic Meters Air Fragrance Machine Scent Diffuser with Intelligently Locked

Description of Perfume Mist Diffuser

• CH119 perfume mist diffuser is easily covering the compact areas which is from 100 to 300 cubic meters such elevators, corridors, toilets and more commercial places and home rooms.

• CH119 model is designed with the automatically locking function of the program, so don’t be afraid others could change the setting data. It is so intelligent.

• The machine is with the built-in fan and ensures that the scent is blown evenly into the air and let the good scent smell much more quickly be full of the whole spaces.

• Comes with the programmable, so it could be set to automatically work during your business hours and stop out of hours. The scent mist intensity of this fragrance machine could be adjustable also. There are total 19 different levels of the intensity to suit well your spaces. Just fill the CH119 150ml bottle with essential oils; it could create the joyful scenting world.

• The scent machine is using advanced cold air diffusion technology. Cold air diffusion is the latest technology in the scenting industry. It works by using high amounts of air pressure to compress oils into a dry mist of nanoparticles. This cold air diffusion technology is used in all diffusing systems and ensures consistent and subtle scenting without high or low points in the scenting process.

Technical Data and Accessory

Model No.: CH119

Shell Material: Anticorrosion Plastic

Color: White, Black

Dimension: 152*73*212mm

Net Weight: 0.7 kg (Light Weight)

Packing Dimension: 48.5*35.6*54.7cm (L*W*H) / 24 pieces

Gross Weight: 24kgs / 24 pieces

Power Supply: DC12V/ 5W

Coverage : 100-300m3

Installation Way: Wall Mounted / Tabletop (Easy Installation)

Essential Oil Bottle Capacity: 150ml

Essential Oil Consumption: 0.05ml to 0.95 ml per hour

Noise Level: < 38dba

Warranty 1: Year

Container Loading 240 cartons, 5760 pieces for 20 feet; 540 cartons, 12960 pieces for 40 feet

Excellence Performance

• Build in quiet fan to make the much quicker aroma full of home or commercial places
• Lower noise, less than 38 dba
• Auto locks function of setting program
• Lower oil consumption
• 19 intensity setting options
• 15 options for the working day setting

Maintenance of Product

In the below cases, please do the maintenance same as our instruction.

• If don't use the scent machine for a long time, please clean the machine after final use.
• Every one- two months clean one time.
• Before change to another flavor of the essential oil
• Cleaning steps as below:

1. Pour out the essential oil from the oil bottle
2. Fill the 95% alcohol into the empty bottle
3. Set the strongest intensity means 95%, and then turn on the machine to work for 10-15 minutes,
4. Turn off it and finally pour away the alcohol.
5. Done
