Specifications
Brand Name :
Meidibao
Model Number :
M-D25ADH
Certification :
CE
Place of Origin :
China
MOQ :
6units
Price :
negotiate a price
Payment Terms :
T/T
Supply Ability :
20units a day
Delivery Time :
25-30 days
Packaging Details :
Factory standard
Fan Direction :
Side
Color :
Galvanized
Power :
380V/3N/50Hz
Operation Condition :
-30°C-40°C
Compressor :
Copeland
Description

Household Dc Inverter Air to Water Source Heat Pump Dc Inverter Air to Water Source Heat Pump

This DC Inverter Air to Water Source Heat Pump is an all-in-one, energy-saving system designed to meet the heating, cooling, and domestic hot water needs of residential homes. Utilizing advanced inverter technology, it adjusts output intelligently based on real-time demand—delivering maximum comfort with minimum energy consumption.

Key Features

  1. DC Inverter Technology

  2. All-Season Comfort

  3. Air Source Heat Pump Water Heating

  4. Hot Water Supply up to 60°C

  5. Reliable Performance

Applications

  • Residential Heating: Warm up homes effectively without skyrocketing energy bills.
  • Commercial Spaces: Ideal for offices, hotels, and retail stores requiring consistent, efficient heating.
  • Industrial Use: Suited for large-scale heating needs in warehouses or factories.
  • Swimming Pools: Maintain pool water at a comfortable temperature year-round.

Why Choose Meidibao EVI Heat Pump?

  • Energy Saving

  • Multi-Functionality

  • Stable and Silent Operation

  • Environmentally Friendly

  • Smart Control Options

  • Wide Ambient Temperature Range

  • Durable and Low Maintenance

  • Easy Installation
    Monoblock design

Specification:

Model M-D25ADH
Heating Capacity Range kW 10.8-36
BTU/h 36849-122832
Heating Power Input Range kW 2.5-9.5
Cooling Capecity Range kW 6.5-21.6
BTU/h 22178-73699
Cooling Power Input Range kW 2.1-8.8
Frequency Hz 30-90
ErP level(35℃) / A++
ErP level(55℃) / A+
Power Supply / 3N 380V 50HZ
Electric Heater kW /
Max.Running Current A 21.8
Refrigerant Type / R410A
Refrigerant Quantity kg 3.3
Compressor Brand / Mitsubishi Electric
Water Pump Brand / WiLo
Water Connection / 1"
Water Flow m³/h 6.2
Water Pressure Drop kPa 10
Water Pump Head m 11.8
Fan Motor Quantity / 2
Motor Power Input(max) W 136
Motor Power Input(min) W 18
Fan Speed (max) rpm 850
Fan Speed (min) rpm 300
Pressure Sensor 1 Bar 0-20
Pressure Sensor 2 Bar 0-45
Noise dB(A) 58
Net Weight kg 183
Gross Weight kg 235
Net Dimension(L/W/H) mm 1370×580×1525
Shippping Dimension(L/W/H) mm 1480×690×1690

Advantages:

Under ideal weather conditions, heat pump water heaters produce three times the energy used to power the heat pump. In other words, heat pump water heaters use one-third of the electricity of conventional electric water heaters. CUB estimates that the average residential customer would save a lot of money per month using a MEIDIBAO heat pump water heater.
