Specifications
Brand Name :
N / M
Model Number :
YF6455BR
Certification :
CE&ROHS
Place of Origin :
CHINA
MOQ :
Negotiation
Price :
Consultation
Payment Terms :
T/T, L/C
Supply Ability :
4000pcs 30 days
Delivery Time :
One month after receiving 30% deposit
Packaging Details :
Bubble Bag with Foam, Color box and Strong Carton
Material :
Chrome
Popularity :
Hot
Brand :
OEM
Origin :
China
Moisture Resistant :
IP67
Application :
On-board air system, car tuning, off-board car
Delivery :
20-30 days after received your deposit
Warranty :
12 months
Description

Yurui 6455BR 150psi 1 Year Warranty Load Support Air Ride Suspension Compressor Bags

► Description

YF6455BR is an installation type air suspension pump, which specifically applies to the professional equipment where needs fast-speed and extensive air, such as tire inflation, agriculture seeder, armaria, extracting oil and even in aircraft manufacturing corporation. Always integrated into on-board air system.

Commonly used must with air tanks in car tuning like off-road cars.The compressor is consist with an on-off pressure button. It automatically turns on and off when the pressure reaches the certain level. The part, air filter can be used in a remote situation when the environment changes. The compressor is furnished with a thermal overload protector which will turn off the unit if overheated.

► Used with

• Air tanks in different sizes

• Pneumatic system

• Air horns

► Our Advantages

1 . One year warranty

2 . Competitive price than other manufactures

3 . Portable to carry with

4 . Fast inflation and low noise

5 . Can be pumped more than 20 , 000 times

6 . Anti-dust and explosion-proof

7 . Water resistant : IP 67, working in the water for 2 hours

► SPECIFICATION

2.18CFM 150PSI

• 12 Volt

• Duty Cycle: 33% @ 100 PSI

• Max. Working Pressure: 150 PSI

• 12V Max. Amp Draw: 25 Amps

• 1/4"NPT Inlet port

• Net Weight: 11 lbs

9.25"Lx4"Wx6.5"H

► PERFORMANCE DATA

PSI 0 40 90 150
AMPS 15 23 24 25
CFM 2.18 1.48 1.2 0.84
LPM 62 42 34 24
BAR 0 3 6 10

► RECOMMENDED TANK4x4 Air Compressor Air Pneumatic Air Suspension Compressor Pump

TANK FILL DATA

2.0 Gallon Tank

0 to 150 psi 2 min 05sec

120 to 150 psi 40 sec

♦ DUTY CYCLE REFERENCE CHART

Duty Cycle: 100PSI @ 72◦F Max. Run Time / Min. Rest Time

Duty cycle refers to the amount of time compressor can be operated in a given time period at 100PSI and a standard ambient temperature of 72◦F. Duty cycle is commonly expressed in percentage format as: Compressor on time / (on time + off time)= Duty Cycle%
9% Duty Cycle 3 Min. On / 30 Min. Off
10% Duty Cycle 3 Min. On / 30 Min. Off
15% Duty Cycle 6 Min. On / 30 Min. Off
20% Duty Cycle 8 Min. On / 30 Min. Off
25% Duty Cycle 10 Min. On / 30 Min. Off
30% Duty Cycle 13 Min. On / 30 Min. Off
33% Duty Cycle 15 Min. On / 30 Min. Off
40% Duty Cycle 20 Min. On / 30 Min. Off
100% Duty Cycle Continous Duty @ 100PSI @ 72◦F
