Gas Filled AS9541 Semi Truck Air Bags W01-358-9541 FLEETPRIDE 1DK20H-9541
Gas Filled AS9541 Semi Truck Air Bags W01-358-9541 FLEETPRIDE 1DK20H-9541
Gas Filled AS9541 Semi Truck Air Bags W01-358-9541 FLEETPRIDE 1DK20H-9541
Gas Filled AS9541 Semi Truck Air Bags W01-358-9541 FLEETPRIDE 1DK20H-9541
Gas Filled AS9541 Semi Truck Air Bags W01-358-9541 FLEETPRIDE 1DK20H-9541
Gas Filled AS9541 Semi Truck Air Bags W01-358-9541 FLEETPRIDE 1DK20H-9541
Specifications
Place of Origin :
Guangdong, China
Brand Name :
VKNTECH
Certification :
IATF16949/ISO9000
Packaging Details :
CARTON/PALLET
Supply Ability :
2000000pcs/Year
MOQ :
20 Pieces
Price :
$1.00 - $45.00/Pieces
Model Number :
1K9541
OE NO. :
W01-358-9541
Warranty :
12 Months
Type :
by sea / by air / by truck
Car Model :
For bus/truck&trailer
Price condition :
FOB China
Sample :
Available
Material :
Imported Natrul Rubber
Operation :
Gas-filled
Brand :
VKNTECH or customized
Service offered :
OEM
Suspension system :
Air Spring Suspension
Type of Goods :
Air Spring/Air bags/Air Ballons
Package :
Standard packing or customized
Payment term :
T/T&L/C
Port :
Guangzhou
Description

AS9541 Natural Rubber Air Spring/W01-358-9541 Air Suspension Spring For OEM Piston Steel 1DK20H-9541 Air Bags


OEM

Firestone W01-358-9541 FLEETPRIDE AS9541
TRIANGLE AS-8861 TRP AS95410
AUTOMANN 1DK20H-9541
KENWORTH C81-1005

Product Drawing

Gas Filled AS9541 Semi Truck Air Bags W01-358-9541 FLEETPRIDE 1DK20H-9541

Specification

Air Spring Air Fitting Size Air Inlet 1 5/16-12 UNF
Air Spring Compressed Height 3.90 in.
Air Spring # of Lobes 1 Solid Sleeve
Air Spring Type 1T - Reversible Sleeve
Bead Plate (Top) & Deflated Bellows O.D. 9 and 9.12 in.
Bead Plate (Top) Mounting Bolts Dimension Center to Center 2.25 in.
Diameter 9.12 in.
Extended Height Deflated 12.00 in.
Finished Weight 11.0 lbs
Piston Height 2.8 in.
Bead Plate Top Diameter 9 in.
Bead Plate Bottom Diameter 8.18 in.
Application Airglide 690
Assembled Product Weight (lb) 11.5
Bellows 1T15LA-0
Bottom Bead Plate Hardware Key Bold or Stud 1/2-13
Design Height (in.) 6月7日
Loading Capacity at 20 psig 1,320 lbsf
Loading Capacity at 60 psig 3,960 lbsf
Loading Capacity at 90 psig 5,940 lbsf
Maximum Diameter 11.7
Maximum Rebound Height (in.) 11.5
Minimum Jounce Height (in.) 3.75
Natural Frequency Hz
Operating Temperature (Deg C) 57 to -54

Product Description

Spring Pro Bellow Number: 889541

Goodyear Bellows Number: n/a

Goodyear Part Number: n/a

Firestone Bellows Number: 1T15LA-0 or 1T15KW-0

Firestone Part Number: W01-358-9541

Replaces: Kenworth C81-1005, Airglide 200 05/05/03 or later, Airglide 460, Airglide 690

Cross References: C811005, 66111, C81-1005, 9 9-10 S 861, 99-10S861, 9910S861, W01-358-9541, W013589541, 9547, W013589547, W01-358-9547, C811004, C81-1004
A cross reference listing means that this air bag may be a suitable replacement for the part numbers listed. Please double check the dimensions and location of mounting holes and stud to be sure the air bag will work in your application.
