Heavy Duty Round Tube Trailer Straight Axle 12000 Pound With 12.25 Inch Brakes
Heavy Duty Round Tube Trailer Straight Axle 12000 Pound With 12.25 Inch Brakes
Specifications
Brand Name :
Airui
Model Number :
AC00100000g
Certification :
ISO/TS16949
Place of Origin :
Shandong，China
MOQ :
Deliberations
Price :
Deliberations
Payment Terms :
L/C, T/T
Supply Ability :
20000 Set/Sets per Month
Delivery Time :
5-8 work days
Packaging Details :
1. Hot shrink poly per set/box and ten boxes in one carton. 2. Pallet packing. 3. As your requirements
Use :
Trailer Parts
Max Payload :
8000-15000 lbs
Size :
12.25 inch Heavy Brake Axles
Material :
Iron
Quality :
100% Guaranteed
Length :
Customer Model
Tube :
100 mm round
Bolts :
8 bolts
Description

Heavy Duty Round Tube Straight 15000 Pound Trailer Axles With 12.25 Inch Brakes

How often should calipers be replaced?

Most brake calipers do not need to be rebuilt or replaced the first time the brakes are relined. But after 75,000 miles, or seven to 10 years of service, the calipers may be reaching the end of the road. As the rubber seals age and harden, the risk of sticking and leaking goes up.

NO. Description QTY option 1 option 2 option 3
1 axle shaft 1 127*8mm round tube 50mm round tube
2 spring seat 2 AC00100104
3 Mounting plate 2 AC00100103
4 Forge spindle 2 AC00100102 AT01200103
5 12.25" brake plate 2 AZ001/D35/071 electric AZ069/070 hydraulic
6 bolt, washer, nut 8,10,14 AC00100501/2/3
7 oil seal 2 AC00100400
8 inner bearing 2 387A/382A
9 hub drum 2 AC00100300
10 wheel retaining ring 2 AC00100900
11 wheel nut 16 AC00100304
12 outer bearing 2 22580/25520
13 castle nut 2 AC00100701
14 split pin 2 AC00100702
15 Oil cap 2 AC00100200

Heavy Duty Round Tube Trailer Straight Axle 12000 Pound With 12.25 Inch BrakesHeavy Duty Round Tube Trailer Straight Axle 12000 Pound With 12.25 Inch Brakes

Features:

Axle Beam Acts as part of your trailer Suspension for hauling loads.

Great for replacing an old axle or bent damaged axle on your trailer

Made of High Strength Steel

Underslung axle design: spring pads are welded to the underside of the axle for mounting leaf springs.

Spring pads are pre-welded on the trailer axle for your convenience.

The 5 lug Hub Drums & Electric Brakes are assembled on the axle and 5 lug idler hubs on other axle with the bearings, seals, pre-greased, fully assembled for simple installation on your trailer.

Great for Utility Trailer Axle, Boat Trailer Axle, Car Haulers Trailer Axle, ATV Trailer Axle, Lawn & Landscape Trailer Axle, Motorcycle Trailer Axle, BBQ Pit Trailer Axle, Cargo Trailer Axle, Enclosed Trailer Axle, RV Trailer Axle & More
