10 Inch 2300 To 3500 Lb Trailer Axle Spindle With Electric Brake Drum
10 Inch 2300 To 3500 Lb Trailer Axle Spindle With Electric Brake Drum
10 Inch 2300 To 3500 Lb Trailer Axle Spindle With Electric Brake Drum
10 Inch 2300 To 3500 Lb Trailer Axle Spindle With Electric Brake Drum
Specifications
Brand Name :
Airui
Model Number :
AC00500000
Certification :
ISO/TS16949
Place of Origin :
Shandong，China
MOQ :
Deliberations
Price :
Deliberations
Payment Terms :
L/C, T/T
Supply Ability :
20000 Set/Sets per Month
Delivery Time :
5-8 work days
Packaging Details :
1. Hot shrink poly per set/box and ten boxes in one carton. 2. Pallet packing. 3. As your requirements
Use :
Axle Parts
OE NO :
AC00500000
Max Payload :
2300-3500 lbs
Product Name :
axle spindle with electric brake drum
MOQ :
100pcs
Size :
10 inch
Material :
steel
Quality :
100% Guaranteed
Description

Trailer Axle Spindles With 10 Inch Parking Level Electric Brake Drum

Can you replace spindles on a trailer?

By no means are we trying to discourage you from attempting a do-it-yourself installation of trailer axle spindles, but unless you're a skilled welder, this may be one of those jobs that are better left to the professionals. It's critical that spindles are properly aligned and secured to the axle. A licensed trailer repair facility should easily be able to install a new spindle or two. Remember, sometimes it may be worth the extra cost to save the time and frustration that can sometimes accompany a difficult (and unfamiliar) repair.

5* 4.5", 6*5.5" wheel pattern
NO. Description QTY option 1 option 2 option 3
1 axle shaft 1 45mm round/square 50mm round/square
2 stub axle 2 AC00500201 AC00500201 AC00500201
3 mounting plate 2 AT01200107 AT01200107 AT01200107
4 10" brake plate 2 AZ013L/R AZ026UR AZ013L/R
5 nut 8 AC00100501 AC00100501 AC00100501
6 washer 8 AC00100502/3 AC00100502/3 AC00100502/3
7 oil seal 2 AC00500201 AC00500201 AC00500201
8 inner bearing 2 L68149/10 L68149/11 L68149/10
9 10" hub drum 2 AC00500300 AC00300300 AC00500300
10 outer bearing 2 LM12749/10 L68149/10 LM12749/10
11 flat washer 2 AC00500402 AC00201001 AC00500402
12 castle nut 2 AC00500403 AC00200701 AC00500403
13 split pin 2 AC00500404 AC00200404 AC00500404
14 dust cap 2 AC00500405 AC00300601 AC00500405
15 drop plate 2 AC00300103 AC00300103 AC00300103
16 wheel nut 10,12 1/2"-10UNF 7/16"-20UNF 1/2"-10UNF

10 Inch 2300 To 3500 Lb Trailer Axle Spindle With Electric Brake Drum10 Inch 2300 To 3500 Lb Trailer Axle Spindle With Electric Brake Drum

FAQ

Q1,What is your package types?
A:Generally, in neutral white boxes and brown cartons or as ur requirements.
Q2,What is your terms of payment?
A: 30% T/T in advance and 70% before shipping or against by BL copy.
Q3,What is your payment terms?
A: EXW,FOB, CNF & CIF.
Q4,How about your delivery time?
A: Usually,within 30-60 days after receiving the deposit or depending on the order’s requirements.
Q5,Can you produce according to the samples?
A:Yes,we can produce by your samples or technical drawing.
Q6,What is your sample price?
A:Sample design is free, sample and the express cost without free.
Q7,Do you test all your product before delivery?
A:Yes,we have 100% test before delivery.
Q8: How to establish the long-term stable business relationship with your company?
A:We can supply good and competitive price cargo to make sure the win-win relationship.
