12 Pin M12 socket type IP67 Panel Mount Circular straight waterproof AISG Connector
12 Pin M12 socket type IP67 Panel Mount Circular straight waterproof AISG Connector
12 Pin M12 socket type IP67 Panel Mount Circular straight waterproof AISG Connector
12 Pin M12 socket type IP67 Panel Mount Circular straight waterproof AISG Connector
12 Pin M12 socket type IP67 Panel Mount Circular straight waterproof AISG Connector
12 Pin M12 socket type IP67 Panel Mount Circular straight waterproof AISG Connector
12 Pin M12 socket type IP67 Panel Mount Circular straight waterproof AISG Connector
12 Pin M12 socket type IP67 Panel Mount Circular straight waterproof AISG Connector
Specifications
Brand Name :
Ritian communication
Model Number :
RET-AISG
Certification :
UL CE ROHS
Place of Origin :
Guangdong, China
MOQ :
100 PCS
Price :
Negotiable
Supply Ability :
10000 Unit/Units per Month
Delivery Time :
1-2weeks
Packaging Details :
Seal PE packing,one pieces packing in a bag then put in a box
Payment Terms :
T/T, Western Union, MoneyGram
Type :
Circular Connector
Gender :
Male And Female
Protection Leve :
IP67
Connector Type :
Circular Connectors
Description :
AISG M16 Connector
Description

12 Pin M12 socket type IP67 Panel Mount Circular straight waterproof AISG Connector

M12 connectors are mainly used in outdoor light boxes, construction machinery, steel production equipment, power equipment, mining machinery, ship machinery, automotive equipment, automatic production equipment, temperature transmitters, hydraulic machine tools, sensors, solenoid valves, instrumentation, pressure change transmitter, etc.

High quality AISG equivalent as Binder eries 423, 581 and Amphenol eries C091A C091D family of connectors are rugged, high-performance circular connectors with excellent EMI shielding and IP67. Ideal choice for severe industrial and commercial applications. Panel-mounted receptacle are available in many styles and mounting methods.

Rugged metal shells

Straight or right-angle cable connector

Right-angle cable connectors adjustable in 4 radial positions

Excellent 360° EMI shielding and IP67

Internal strain relief

2 to 24 contacts,gold(Au)- or silver(Ag)-plated

Characteristics of M16 Series

General Characteristics
Number of contact 2 3DIN 4 5 5DIN 6DIN 7 7DIN 8DIN 12 14 19 24
Locking system screw M16*0.75
Termination solder, moulded on cable
Wire guage in mm² max 0.75 max 0.25 0.14
Wire guage in AWG max 20 max 24 26
Shell protection IP67/IP68
Mechanical operation >500 mating cycles
Upper temperature +85℃
Lower temperature -25℃
Electrical Characteristics
Rated voltage 250V 60V 250V 125V 60V
Test voltage 1750V 550V 1750V 910V 550V
Rated current(40℃) 7A 6A 5A 3A 1A
Pollution degree III
Contact resistance ≤5mΩ ≤3mΩ
Insulation resistance ≥10³MΩ
Materials
Pin contact CuZn
Socket contact CuSn
contact plating Au
Upper temperature PA66(UL 94V-0)
Female insent PA66(UL 94V-0)
Material of cable jacket PVC or PUR
Screw CuZn
Nut CuZn

12 Pin M12 socket type IP67 Panel Mount Circular straight waterproof AISG Connector12 Pin M12 socket type IP67 Panel Mount Circular straight waterproof AISG Connector12 Pin M12 socket type IP67 Panel Mount Circular straight waterproof AISG Connector

OUr Services:

1.100% high quality, all failed parts get free warranty within 30 days after received.

2.Accept warranty upon customer requirement.

3.Repairs parts are available within 3 years; we will inform the EOL products to you from time to time

4.Unique designed package for you can be provided upon customer requirement.

5.Special feature and service can be provided upon requirement.
