Specifications
Brand Name :
AISON
Model Number :
Z070WV01
Certification :
ISO9001 / ISO14000/ROHS
Place of Origin :
Guangdong,China
MOQ :
1
Price :
Negotiable based on quantity
Payment Terms :
T/T, Western Union, MoneyGram,Paypal
Supply Ability :
200k/month
Delivery Time :
7 working days
Packaging Details :
Carton/Blister Package
Name :
TFT Panel
Resolution :
800x480
Outline dimension :
164.9*100*5.7mm
Active area :
154.08 x 85.92mm
Interface :
24 bit RGB
Brightness :
450cd/m2
LCD Type :
TFT, Normally White, Transmissive
Contrast Ratio :
500:1
Operating temperatures :
-20℃ To +70℃
Storage temperatures :
-30℃ To +80℃
Description

7 inch 800x480 TFT LCD Display Module with 24 BIT RGB Interface 40Pin

General Description
Z070WV01 is a color TFT LCD module with a resolution of 800x480 pixels and a diagonal size of 7 inches. The module dimensions are 164.9 x 100 mm, and the active area size is 154.08 x 85.92 mm. This TFT model is built-in with HX8264-D,HX8664-B driver ICs. Z070WV01 supports a 24-bit RGB interface.

It features an anti-glare surface, a contrast ratio of 500:1 (typical value), and a brightness of 400 nits (typical value). The view direction is 12 o'clock, grayscale inversion is at 6 o'clock, and the aspect ratio is 16:9. The supply voltage for logic (VCC) of Z070WV01 ranges from 3.0V to 3.6V, with a typical value of 3.3V. It can operate at temperatures from -20°C to +70°C and storage temperatures from -30°C to +80°C.

This 7-inch TFT LCD module is well-suited for applications in industrial control equipment, testing devices, medical equipment, and smart home devices, among others. Due to its versatility, this TFT LCD module is suitable for a variety of application scenarios.

General Data

Model Name 7 inch TFT LCD Panel
Resolution 800*(RGB)*480
Model Size (W*H*T)mm 164.9*100*5.7mm
Display Area (W*H)mm 154.08 x 85.92mm
Interface RGB
Display Mode Normally White TN,Transmissive
Viewing 12:00 o'clock
Brightness 400 cd/m2
Pin number 40 pin
Interface RGB 24 bit
Operating temperatures -20 to 70 degree
Storage temperatures -30 to 80 degree

Drawing

7 Inch TFT Panel 450 cd/m2 40 Pin Panel 800x480 With 24 BIT RGB Interface 40Pin

Product Details

7 Inch TFT Panel 450 cd/m2 40 Pin Panel 800x480 With 24 BIT RGB Interface 40Pin7 Inch TFT Panel 450 cd/m2 40 Pin Panel 800x480 With 24 BIT RGB Interface 40Pin

TFT Applications:

This 7-inch TFT LCD module is well-suited for applications in industrial control equipment, testing devices, medical equipment, and smart home devices, among others. Due to its versatility, this TFT LCD module is suitable for a variety of application scenarios.
