5 inch IPS TFT Display Module 800x480 Industrial Capacitive Touch Screen 500 Cd/M2
5 inch IPS TFT Display Module 800x480 Industrial Capacitive Touch Screen 500 Cd/M2
5 inch IPS TFT Display Module 800x480 Industrial Capacitive Touch Screen 500 Cd/M2
5 inch IPS TFT Display Module 800x480 Industrial Capacitive Touch Screen 500 Cd/M2
5 inch IPS TFT Display Module 800x480 Industrial Capacitive Touch Screen 500 Cd/M2
5 inch IPS TFT Display Module 800x480 Industrial Capacitive Touch Screen 500 Cd/M2
Specifications
Brand Name :
AISON
Model Number :
Z050WV21
Certification :
ISO9001 / ISO14000/ROHS
Place of Origin :
Guangdong,China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram,Paypal
Supply Ability :
200k/month
Delivery Time :
7 working days
Packaging Details :
Carton/Blister
Name :
5 inch IPS TFT Display
Resolution :
800x480
Outline dimension :
120.7*75.8*2.9mm
Active area :
108x64.8 mm
Interface :
LVDS
Brightness :
500 cd/m2
Operating temperatures :
-30 to 80 degree
Storage temperatures :
-35 to 85 degree
Description

5 Inch 800x480 IPS TFT LCD Display Module With LVDS Interface High Temp. Automotive Grade

General Description

Z050WV21 is 5 inch 800x480 resolution LCD display with LVDS interface, standard brightness is 500cd/m2. For this 5 inch TFT LCD module, driver IC is ST7262A, Wide working temp. from -30 to +80,storage temperatures -35 to 85 degree, viewing direction is Free. color depth is 16.7M, operating voltage is 3.3V, this lcd module can be with resistive or capacitive touch panel, customized design are also welcome. this 5 inch lcd is suitable for industrial grade and automotive application.

General Data

Product Name 5 Inch LVDS TFT LCD Module
Number of Pixel 800x480
Interface LVDS
Luminance(cd/m2) 500cd/m2
Active area
120.7*75.8*2.9 mm
LCM (W x H x D)
108x64.8 mm
Viewing Direction(eye) IPS/ALL
Operating temperatures -30 to 80 degree
Storage temperatures -35 to 85 degree

Drawing

5 inch IPS TFT Display Module 800x480 Industrial Capacitive Touch Screen 500 Cd/M2

Product Details

5 inch IPS TFT Display Module 800x480 Industrial Capacitive Touch Screen 500 Cd/M25 inch IPS TFT Display Module 800x480 Industrial Capacitive Touch Screen 500 Cd/M2

TFT Applications

The 5 inch IPS 800x480 LVDS TFT Displays are widely used for Industrial, Smart home,Medical, Automotive ,Intelligent and other applications.
