Himo Longi Solar 400w Full Black 410W 415W 425W Monocrystalline Photovoltaic Panels
Himo Longi Solar 400w Full Black 410W 415W 425W Monocrystalline Photovoltaic Panels
Specifications
Model Number :
LR5-54HTB(410-425W)
Place of Origin :
Jiangsu, China
MOQ :
1
Price :
To be negotiated
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200000 Watt/Watts per Week
Delivery Time :
To be negotiated
Packaging Details :
pallet
Brand Name :
Longi
Certification :
CGC，ISO9001:2015，TUV SUD，PV，CNAS，
Material :
Monocrystalline Silicon
Panel Dimensions :
1722x1134x30mm
Cell size :
182mm*182mm
Type :
PERC, Half Cell, All Black
Panel Efficiency :
21.8%
Certificate :
CE TUV IEC, TUV CE IEC
Description

LONGI 410W 415W 420W 425W 108Cells Himo Photovoltaic Panels Monocrystalline All Full Black Modules Solarmodules

Cell Orientation
108(6x18)
Junction Box
IP68,three diodes
Output Cable
4mm²,±1200mm
length can be customized
Glass
Single glass, 3.2mm coated tempered glass
Frame
Anodized aluminum alloy frame
Weight
20.8kg
Dimension
1722x1134x30mm
Packaging
36 pcs per pallet /216 pcs per 20'GP/936 pcs per 40'HC

Model No. LR5-54HTB-410M LR5-54HTB-415M LR5-54HTB-420M LR5-54HTB-425M LR5-54HTB-430M
Warranty
Product Warranty 15 Years
Power Warranty 15 Years of 92.9% Output Power, 25 Years of 88.9% Output Power
Electrical Data at STC
Maximum Power (Pmax) 410 Wp 415 Wp 420 Wp 425 Wp 430 Wp
Voltage at Maximum Power (Vmpp) 32.36 V 32.56 V 32.76 V 32.96 V 33.16 V
Current at Maximum Power (Impp) 12.67 A 12.75 A 12.83 A 12.9 A 12.97 A
Open Circuit Voltage (Voc) 38.63 V 38.83 V 39.03 V 39.23 V 39.43 V
Short Circuit Current (Isc) 13.7 A 13.78 A 13.85 A 13.93 A 14 A
Panel Efficiency 21% 21.30% 21.50% 21.80% 22%
Power Tolerance (Positive) 3% 3% 3% 3% 3%
Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m2, cell temperature 25°C
Electrical Data at NOCT
Maximum Power (Pmax) 306 Wp 310 Wp 314 Wp 318 Wp 321 Wp
Voltage at Maximum Power (Vmpp) 29.53 V 29.71 V 29.89 V 30.08 V 30.26 V
Current at Maximum Power (Impp) 10.37 A 10.44 A 10.5 A 10.56 A 10.62 A
Open Circuit Voltage (Voc) 36.27 V 36.46 V 36.65 V 36.83 V 37.02 V
Short Circuit Current (Isc) 11.07 A 11.13 A 11.19 A 11.25 A 11.31 A
Temperature 45±2 °C
Nominal Operating Cell Temperature (NOCT): 800W/m2, AM 1.5, windspeed 1m/s,ambient temperature 20°C
Thermal Ratings
Operating Temperature Range 40~85 °C
Temperature Coefficient of Pmax 0.29 %/°C
Temperature Coefficient of Voc 0.23 %/°C
Temperature Coefficient of Isc 0.05 %/°C
Maximum Ratings
Maximum System Voltage 1500 V
Series Fuse Rating 25 A
Material Data
Panel Dimension (H/W/D) 1722x1134x30 mm
Weight 20.8 kg
Cell Type IBC
Cell Number 108
Glass Type Tempered
Glass Thickness 3.2 mm
Frame Type Anodized Aluminium Alloy
Junction Box Diodes 3
Junction Box Protection Class IP 68
Cable Crossection 4 mm2
Cable Length 1200 mm

Himo Longi Solar 400w Full Black 410W 415W 425W Monocrystalline Photovoltaic PanelsHimo Longi Solar 400w Full Black 410W 415W 425W Monocrystalline Photovoltaic Panels

Himo Longi Solar 400w Full Black 410W 415W 425W Monocrystalline Photovoltaic Panels

Himo Longi Solar 400w Full Black 410W 415W 425W Monocrystalline Photovoltaic Panels

Himo Longi Solar 400w Full Black 410W 415W 425W Monocrystalline Photovoltaic PanelsHimo Longi Solar 400w Full Black 410W 415W 425W Monocrystalline Photovoltaic Panels

FAQ
Q:Are you a factory or a trading company?
A:We are a professional Solar Panels Manufacturer in China
Q:How can we guarantee the products quality?
A:Always provide the esteemed buyer a pre-production sample before mass production; Always testing every product before despatching the shipments;
Q:What products we can supply you?
A:Solar Panel,Inverter,Mounting System,Battery,Pv Cable,Distributor Box,Pv Connector,Etc

Q:Can the products pricing be cheaper?
A:Of course, you will be offered a a very good discount with large quantities.
Q: Can print our company‘s logo on the pv panels?
A:Yes! And we accept the OEM&ODM orders.
