610W 615W Jinko Solar Panel 620W 625W 630W Monocrystalline Perc Solar Panel
610W 615W Jinko Solar Panel 620W 625W 630W Monocrystalline Perc Solar Panel
Specifications
Model Number :
Tiger Neo N-type 78HL4-(V)(610-630 Watt)
Place of Origin :
Jiangsu, China
MOQ :
1
Price :
To be negotiated
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200000 Watt/Watts per Week
Delivery Time :
To be negotiated
Packaging Details :
pallet
Brand Name :
Jinko solar
Certification :
CGC，ISO9001:2015，TUV SUD，PV，CNAS，
Cell size :
182mmx182mm
Panel Dimensions :
2465x1134x35mm
Customization :
Customized logo(Min. order 100000 watts) Customized packaging(Min. order 100000 watts) Graphic customization(Min. order 100000 watts)
Type :
PERC, Half Cell, N-TYPE
Panel Efficiency :
22.54%
Certificate :
TUV/CGC/CE
Description

Jinko 610W 615W 620W 625W 630W solar panels monocrystalline solar panel black solar panel

The long-term durability of PERC solar panels is another advantage that sets them apart from conventional solar panels. The passivation layer added to the rear side of the cell not only enhances efficiency but also provides additional protection against environmental factors such as moisture, dust, and UV radiation. This added protection contributes to the overall longevity of the panel, ensuring that it continues to generate electricity efficiently for an extended period. With a typical lifespan of 25-30 years, PERC solar panels provide a reliable and long-lasting renewable energy source for homeowners and businesses.

Cell Type
N type Mono-crystalline
No.of cells
156 (2×78)
Dimensions
2465×1134×35mm (97.05×44.65×1.38 inch)
Weight
30.6 kg (67.46 lbs)
Front Glass
3.2mm,Anti-Reflection Coating,
High Transmission, Low Iron, Tempered Glass
Frame
Anodized Aluminium Alloy
Junction Box
IP68 Rated
Output Cables
TUV 1x4.0mm2
(+): 400mm , (-): 200mm or Customized Length

Model No. JKM610N-78HL4/JKM610N-78HL4-V JKM615N-78HL4/JKM615N-78HL4-V JKM620N-78HL4/JKM620N-78HL4-V JKM625N-78HL4/JKM625N-78HL4-V JKM630N-78HL4/JKM630N-78HL4-V
Warranty
Product Warranty 12 Years
Power Warranty 30 Years of 87.4% Output Power
Electrical Data at STC
Maximum Power (Pmax) 610 Wp 615 Wp 620 Wp 625 Wp 630 Wp
Voltage at Maximum Power (Vmpp) 45.59 V 45.69 V 45.79 V 45.92 V 46.02 V
Current at Maximum Power (Impp) 13.38 A 13.46 A 13.54 A 13.61 A 13.69 A
Open Circuit Voltage (Voc) 55.25 V 55.4 V 55.55 V 55.7 V 55.85 V
Short Circuit Current (Isc) 14.11 A 14.18 A 14.25 A 14.32 A 14.39 A
Panel Efficiency 21.82% 22% 22.18% 22.36% 22.54%
Power Tolerance (Positive) 3% 3% 3% 3% 3%
Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m2, cell temperature 25°C
Electrical Data at NOCT
Maximum Power (Pmax) 459 Wp 462 Wp 466 Wp 470 Wp 474 Wp
Voltage at Maximum Power (Vmpp) 42.28 V 42.39 V 42.5 V 42.61 V 42.72 V
Current at Maximum Power (Impp) 10.85 A 10.91 A 10.97 A 11.03 A 11.09 A
Open Circuit Voltage (Voc) 52.48 V 52.62 V 52.77 V 52.91 V 53.05 V
Short Circuit Current (Isc) 11.39 A 11.45 A 11.5 A 11.56 A 11.62 A
Temperature 45±2 °C
Nominal Operating Cell Temperature (NOCT): 800W/m2, AM 1.5, windspeed 1m/s,ambient temperature 20°C
Thermal Ratings
Operating Temperature Range 40~85 °C
Temperature Coefficient of Pmax 0.3 %/°C
Temperature Coefficient of Voc 0.25 %/°C
Temperature Coefficient of Isc 0.046 %/°C
Maximum Ratings
Maximum System Voltage 1500 V
Series Fuse Rating 25 A
Material Data
Panel Dimension (H/W/D) 2465x1134x35 mm
Weight 30.6 kg
Cell Type Monocrystalline
Cell Number 156
Glass Type Anti-reflection Coating, Tempered
Glass Thickness 3.2 mm
Frame Type Anodized Aluminium Alloy
Junction Box Protection Class IP 68
Cable Crossection 4 mm2

610W 615W Jinko Solar Panel 620W 625W 630W Monocrystalline Perc Solar Panel610W 615W Jinko Solar Panel 620W 625W 630W Monocrystalline Perc Solar Panel

610W 615W Jinko Solar Panel 620W 625W 630W Monocrystalline Perc Solar Panel

610W 615W Jinko Solar Panel 620W 625W 630W Monocrystalline Perc Solar Panel

610W 615W Jinko Solar Panel 620W 625W 630W Monocrystalline Perc Solar Panel610W 615W Jinko Solar Panel 620W 625W 630W Monocrystalline Perc Solar Panel

FAQ
Q:Are you a factory or a trading company?
A:We are a professional Solar Panels Manufacturer in China
Q:How can we guarantee the products quality?
A:Always provide the esteemed buyer a pre-production sample before mass production; Always testing every product before despatching the shipments;
Q:What products we can supply you?
A:Solar Panel,Inverter,Mounting System,Battery,Pv Cable,Distributor Box,Pv Connector,Etc

Q:Can the products pricing be cheaper?
A:Of course, you will be offered a a very good discount with large quantities.
Q: Can print our company‘s logo on the pv panels?
A:Yes! And we accept the OEM&ODM orders.
