Specifications
Model Number :
Tiger Neo N-type 72HL4-(V)
Place of Origin :
Jiangsu, China
MOQ :
30
Price :
$0.18~0.22/Watt
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200000 Watt/Watts per Week
Delivery Time :
To be negotiated
Packaging Details :
pallet
Brand Name :
Jinko solar
Certification :
CGC，ISO9001:2015，TUV SUD，PV，CNAS，
Cell size :
182mmx182mm
Panel Dimensions :
2278x1134x35mm
Customization :
Customized logo(Min. order 100000 watts) Customized packaging(Min. order 100000 watts) Graphic customization(Min. order 100000 watts)
Type :
PERC, Half Cell, Bifacial, Double-glass
Panel Efficiency :
22.65%
Certificate :
TUV/CGC/CE
Description

Jinko 565W 570W 575W 580W 585W solar panel bifacial double glass solar panels hjt bifacial solar panel

Jinko's Bifacial Double Glass Solar Panels are cutting-edge photovoltaic modules that utilize advanced technology to generate clean and renewable electricity. These panels feature a double-sided design, allowing them to capture sunlight from both the front and rear sides, significantly increasing their energy production.

With power outputs ranging from 565W to 585W, these solar panels offer exceptional performance, making them suitable for various residential, commercial, and utility-scale applications. The high wattage output enables them to generate a significant amount of energy, maximizing the return on investment for solar projects.

Model No. JKM565N-72HL4/JKM565N-72HL4-V JKM570N-72HL4/JKM570N-72HL4-V JKM575N-72HL4/JKM575N-72HL4-V JKM580N-72HL4/JKM580N-72HL4-V JKM585N-72HL4/JKM585N-72HL4-V
Warranty
Product Warranty 12 Years
Power Warranty 15 Years of 93.40% Output Power, 30 Years of 84.7% Output Power
Electrical Data at STC
Maximum Power (Pmax) 565 Wp 570 Wp 575 Wp 580 Wp 585 Wp
Voltage at Maximum Power (Vmpp) 41.92 V 42.07 V 42.22 V 42.37 V 42.52 V
Current at Maximum Power (Impp) 13.48 A 13.55 A 13.62 A 13.69 A 13.76 A
Open Circuit Voltage (Voc) 50.6 V 50.74 V 50.88 V 51.02 V 51.16 V
Short Circuit Current (Isc) 14.23 A 14.31 A 14.39 A 14.47 A 14.55 A
Panel Efficiency 21.80% 22.07% 22.26% 22.45% 22.65%
Power Tolerance (Positive) 3% 3% 3% 3% 3%
Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m2, cell temperature 25°C
Electrical Data at NOCT
Maximum Power (Pmax) 425 Wp 429 Wp 432 Wp 436 Wp 440 Wp
Voltage at Maximum Power (Vmpp) 39.38 V 39.51 V 39.6 V 39.69 V 39.81 V
Current at Maximum Power (Impp) 10.79 A 10.85 A 10.92 A 10.99 A 11.05 A
Open Circuit Voltage (Voc) 48.06 V 48.2 V 48.33 V 48.46 V 48.6 V
Short Circuit Current (Isc) 11.49 A 11.55 A 11.62 A 11.68 A 11.75 A
Temperature 45±2 °C
Nominal Operating Cell Temperature (NOCT): 800W/m2, AM 1.5, windspeed 1m/s,ambient temperature 20°C
Thermal Ratings
Operating Temperature Range 40~85 °C
Temperature Coefficient of Pmax 0.3 %/°C
Temperature Coefficient of Voc 0.25 %/°C
Temperature Coefficient of Isc 0.046 %/°C
Maximum Ratings
Maximum System Voltage 1500 V
Series Fuse Rating 25 A
Material Data
Panel Dimension (H/W/D) 2278x1134x35 mm
Weight 28 kg
Cell Type Monocrystalline
Cell Number 144
Glass Type Anti-reflection Coating, Tempered
Glass Thickness 3.2 mm
Frame Type Anodized Aluminium Alloy
Junction Box Protection Class IP 68
Cable Crossection 4 mm2

565W 570W Jinko Solar Panel 575W 580W 585W Bifacial Mono Perc Double Glass Module

565W 570W Jinko Solar Panel 575W 580W 585W Bifacial Mono Perc Double Glass Module

565W 570W Jinko Solar Panel 575W 580W 585W Bifacial Mono Perc Double Glass Module565W 570W Jinko Solar Panel 575W 580W 585W Bifacial Mono Perc Double Glass Module

565W 570W Jinko Solar Panel 575W 580W 585W Bifacial Mono Perc Double Glass Module

565W 570W Jinko Solar Panel 575W 580W 585W Bifacial Mono Perc Double Glass Module

565W 570W Jinko Solar Panel 575W 580W 585W Bifacial Mono Perc Double Glass Module565W 570W Jinko Solar Panel 575W 580W 585W Bifacial Mono Perc Double Glass Module

FAQ
Q:Are you a factory or a trading company?
A:We are a professional Solar Panels Manufacturer in China
Q:How can we guarantee the products quality?
A:Always provide the esteemed buyer a pre-production sample before mass production; Always testing every product before despatching the shipments;
Q:What products we can supply you?
A:Solar Panel,Inverter,Mounting System,Battery,Pv Cable,Distributor Box,Pv Connector,Etc

Q:Can the products pricing be cheaper?
A:Of course, you will be offered a a very good discount with large quantities.
Q: Can print our company‘s logo on the pv panels?
A:Yes! And we accept the OEM&ODM orders.
