440W 445W Jinko Mono Solar Panels 450W 455W 460W Full Black Solar Panels
440W 445W Jinko Mono Solar Panels 450W 455W 460W Full Black Solar Panels
Specifications
Model Number :
Tiger Pro 60HC(440-460 Watt)
Place of Origin :
Jiangsu, China
MOQ :
30pcs
Price :
To be negotiated
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200000 Watt/Watts per Week
Delivery Time :
To be negotiated
Packaging Details :
pallet
Brand Name :
Jinko solar
Certification :
CGC，ISO9001:2015，TUV SUD，PV，CNAS，
Cell size :
182mmx182mm
Panel Dimensions :
1903x1134x30mm
Customization :
Customized logo(Min. order 100000 watts) Customized packaging(Min. order 100000 watts) Graphic customization(Min. order 100000 watts)
Type :
PERC, Half Cell, All Black, N-TYPE
Panel Efficiency :
21.32%
Certificate :
TUV/CGC/CE
Description

Jinko 440W 445W 450W 455W 460W Black Solar Panel Solar Panels China Ready For Pick Up

The Passivated Emitter Rear Cell (PERC) solar panel technology has emerged as one of the most advanced and efficient solar panel designs in the renewable energy industry. One of the primary advantages of PERC solar panels is their significantly higher efficiency compared to conventional solar panels. This enhanced efficiency is achieved through the implementation of a passivation layer on the rear side of the solar cell, which reduces electron recombination and increases light absorption. This results in more electricity generation per square foot, making PERC solar panels an ideal choice for those looking to maximize their energy production within a limited space. Furthermore, the increased efficiency of PERC solar panels also translates to a higher return on investment (ROI) for homeowners and businesses, as they can generate more electricity and thus save more on their energy bills over time.

Cell
P type Mono-crystalline
Weight
24.2kg
Dimensions
1903×1134×30mm (74.92×44.65×1.18 inch)
Output Cables
TUV 1x4.0mm2(+): 290mm,(-): 145mm or Customized Length
No.of cells
120 (6×20)
Junction Box
IP68 Rated
Connector
MC4-EVO2/ QC 4.10-35
Front Glass
3.2mm,Anti-Reflection Coating,

High Transmission, Low Iron, Tempered Glass
Maximum system voltage
1000/1500VDC (IEC)
Maximum series fuse rating
25A

Model No. JKM450M-60HL4/JKM450M-60HL4-V JKM455M-60HL4/JKM455M-60HL4-V JKM460M-60HL4/JKM460M-60HL4-V JKM465M-60HL4/JKM465M-60HL4-V JKM470M-60HL4/JKM470M-60HL4-V
Warranty
Product Warranty 12 Years
Power Warranty 25 Years of 84.8% Output Power
Electrical Data at STC
Maximum Power (Pmax) 450 Wp 455 Wp 460 Wp 465 Wp 470 Wp
Voltage at Maximum Power (Vmpp) 33.91 V 34.06 V 34.2 V 34.37 V 34.56 V
Current at Maximum Power (Impp) 13.27 A 13.36 A 13.45 A 13.53 A 13.6 A
Open Circuit Voltage (Voc) 41.18 V 41.33 V 41.48 V 41.3 V 41.78 V
Short Circuit Current (Isc) 13.85 A 13.93 A 14.01 A 14.09 A 14.17 A
Panel Efficiency 20.85% 21.08% 21.32% 21.55% 21.78%
Power Tolerance (Positive) 3% 3% 3% 3% 3%
Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m2, cell temperature 25°C
Electrical Data at NOCT
Maximum Power (Pmax) 335 Wp 339 Wp 342 Wp 346 Wp 350 Wp
Voltage at Maximum Power (Vmpp) 31.73 V 31.91 V 32.07 V 32.12 V 32.32 V
Current at Maximum Power (Impp) 10.55 A 10.61 A 10.67 A 10.77 A 10.82 A
Open Circuit Voltage (Voc) 38.87 V 39.01 V 39.15 V 39.29 V 39.43 V
Short Circuit Current (Isc) 11.19 A 11.25 A 11.32 A 11.38 A 11.344 A
Temperature 45±2 °C
Nominal Operating Cell Temperature (NOCT): 800W/m2, AM 1.5, windspeed 1m/s,ambient temperature 20°C
Thermal Ratings
Operating Temperature Range 40~85 °C
Temperature Coefficient of Pmax 0.35 %/°C
Temperature Coefficient of Voc 0.28 %/°C
Temperature Coefficient of Isc 0.048 %/°C
Maximum Ratings
Maximum System Voltage 1500 V
Series Fuse Rating 25 A
Material Data
Panel Dimension (H/W/D) 1903x1134x30 mm
Weight 24.2 kg
Cell Type Monocrystalline
Cell Number 120
Glass Type Anti-reflection Coating, Tempered
Glass Thickness 3.2 mm
Frame Type Anodized Aluminium Alloy
Junction Box Protection Class IP 68
Cable Crossection 4 mm2

440W 445W Jinko Mono Solar Panels 450W 455W 460W Full Black Solar Panels440W 445W Jinko Mono Solar Panels 450W 455W 460W Full Black Solar Panels

440W 445W Jinko Mono Solar Panels 450W 455W 460W Full Black Solar Panels

440W 445W Jinko Mono Solar Panels 450W 455W 460W Full Black Solar Panels

440W 445W Jinko Mono Solar Panels 450W 455W 460W Full Black Solar Panels440W 445W Jinko Mono Solar Panels 450W 455W 460W Full Black Solar Panels

FAQ
Q:Are you a factory or a trading company?
A:We are a professional Solar Panels Manufacturer in China
Q:How can we guarantee the products quality?
A:Always provide the esteemed buyer a pre-production sample before mass production; Always testing every product before despatching the shipments;
Q:What products we can supply you?
A:Solar Panel,Inverter,Mounting System,Battery,Pv Cable,Distributor Box,Pv Connector,Etc

Q:Can the products pricing be cheaper?
A:Of course, you will be offered a a very good discount with large quantities.
Q: Can print our company‘s logo on the pv panels?
A:Yes! And we accept the OEM&ODM orders.
