3003 H14 High Strength Round Aluminum Tube 0.7 - 2.0mm For Heat Exchanger
3003 H14 High Strength Round Aluminum Tube 0.7 - 2.0mm For Heat Exchanger
3003 H14 High Strength Round Aluminum Tube 0.7 - 2.0mm For Heat Exchanger
3003 H14 High Strength Round Aluminum Tube 0.7 - 2.0mm For Heat Exchanger
Specifications
Brand Name :
Yun Neng
Model Number :
3003
Certification :
ISO9001 ISO14001 ISO45001
Place of Origin :
Changzhou China
MOQ :
3 tons
Price :
negotiation
Payment Terms :
T/T
Supply Ability :
50,000 mt per year
Delivery Time :
30 working days after received your down payment
Packaging Details :
Standard export packaging
Product Name :
Aluminum Alloy Calandria
Outside Diameter :
7-30mm Or Customized
Wall Thickness :
0.7-2.0mm Or Customized
Salt spray corrosion test :
> 1500 hours
Yield Strength /Mpa :
≥110
Elongation after break A50mm :
≥5%
Tensile Strength/Mpa :
130-165
State :
H14
Shape :
Coil
Description

High Tensile Aluminium Tube Flat Plate Solar Collector Calandria 3003 H14​

Product Description:

Tube-plate heat-absorbing plate

Flat plate solar collector tube-plate heat-absorbing plate is to connect the row of tubes with the flat plate in a certain way to form heat-absorbing strips, and then welded with the upper and lower collector tubes to form the heat-absorbing plate of the flat plate solar collector. This is the more common type of heat-absorbing plate structure used at home and abroad.

Applications:

Flat-panel solar energy collector

solar collector

heat exchanger

Solar tube

Vacuum solar tube

Wall-mounted flat plate collector

Large solar energy collector

Technical Parameters:

Aluminum Alloy Calandria

Product Name

Model Number

(Material)

 State Salt Spray Corrosion Test >1500 hours Pressure Resistance ＞15 Mpa
Outside Diameter/mm Thickness/mm Tensile Strength/Mpa Yield Strength /Mpa Elongation Length/mm Shape

Main Size

Example

 3003 H14 7-30 0.7-2.0 130-165 ≥110 ≥5%

Customized

 Coil
H12 115-150 ≥75 ＞12%
O 95-130 ＞60 ≥30%
Calandria

H14,

H12,

O

 10

0.8-1.2

 Customized
8
12
Can customize the production of a variety of specifications of the collector tubes.

HOW TO ORDER

​

Firstly,here is a more detailed product description about Aluminum Alloy Tubes of Heat Exchanger.

Flat Panel Solar.pdf

Flat Panel Solar Enercy Aluminum Alloy Tube-PP.pd...​

You can then download a form from this website and fill it out with basic details.

Send it to the provided e-mail address, and our engineers will price you based on the technical specifications.

http://mao.ecer.com/test/al-tubes.com/cases/how-to-order-15643.html

Alternatively, you can download the Technical Data Requirements Sheet directly.

Yuneng Product Requirements Table.docx
