Specifications
Brand Name :
Yun Neng
Model Number :
1050
Certification :
ISO9001 ISO14001 ISO45001
Place of Origin :
Changzhou, China
MOQ :
3 tons
Price :
negotiation
Payment Terms :
T/T
Supply Ability :
50,000 mt per year
Delivery Time :
30 working days after received your down payment
Packaging Details :
Standard export packaging
Product Name :
Aluminum Coil Tubing
Application :
Power Plant Water Cooling Tower, Surface Condenser,Air-conditioner, Refrigerator
Material :
Aluminum Or Aluminum Alloy
Color :
Silver
Tensile Strength /MPa :
100-135
Non-proportional Elongation Strength :
≥ 80Mpa
Elongation After Break :
A50mm ≥ 5%
Outside Diameter :
24mm
Wall Thickness :
0.8mm
Length :
6000mm
Maximum Length :
16 Meters
Specification :
According To The National Standards Or According To Customer Special Requirements For Customization
Description
1050 Aluminum Coil Tubing for Superior Weldability and Conductivity
Specially crafted for large power stations, the Large heat exchange equipment plays a pivotal role in dispersing waste heat produced during power generation. It effectively dissipates this heat into the atmosphere, thereby ensuring the equipment operates at its peak performance.
1050 Aluminum Coil Tubing For Superior Weldability And Conductivity
By infusing a mere trace of iron into pure aluminum, 1050 is born, boasting remarkable forming and processing capabilities, exceptional corrosion resistance, superior weldability, and electrical conductivity. Its versatile properties have made 1050a a highly sought-after option for applications that do not necessitate peak strength.
Features:
Extruded Aluminum Tubes

While not possessing the structural and strength properties of seamless aluminum tubes, this material excels in terms of cost reduction due to its heightened production efficiency and comparably straightforward manufacturing process. Additionally, it boasts remarkable processing flexibility, with its longitudinal (extrusion direction) mechanical properties significantly surpassing those of similar products.

Applications:


Large peak cooler
surface condenser
Large heat exchange equipment
condensator
evaporimeter
etc.

Technical Parameters:

Industrial pure aluminum are characterized by high plasticity, corrosion resistance, good electrical and thermal conductivity, but low strength, can not be strengthened by heat treatment, cuttability is not good; can accept contact welding . Gas welding.

1- Appearance Aluminium tubes without defect, without blow on its surface, without scratches, without pollution like grease or oil.
2- Alloy Grade 1050

3- Composition of alloy (%)

Fe

Mg

Mn

Ti

Al

Autres (others)

0.40

0.05

0.05

0.05

99.50

0.05

Model

Name

Model

Number

Outside

Diameter /mm

Wall Thickness/mm

Maximum

Length/m

Length/mm Tensile Strength /MPa

Non-

proportional

Elongation Strength /MPa

Elongation After Break A50/mm
Main Size

Series 1,

Series 3

20-32 0.8-2.0 5000-15000
Example 1050A 28 1.0 18 7969

100~135

≥80 ≥5.00
25 0.9 6959
23 1.5 9365
32 1.3 12266
