High Purity Magnesium Alloy Tube AZ91D Pipe With Superior Corrosion Performance
High Purity Magnesium Alloy Tube AZ91D Pipe With Superior Corrosion Performance
High Purity Magnesium Alloy Tube AZ91D Pipe With Superior Corrosion Performance
High Purity Magnesium Alloy Tube AZ91D Pipe With Superior Corrosion Performance
Specifications
Brand Name :
DOME
Model Number :
DM011
Certification :
ISO9001,CE,SGS
Place of Origin :
Zhengzhou,China
MOQ :
10KG
Price :
USD30~50/KGS
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
Within Days
Packaging Details :
In carton, on pallet
Name :
High Purity Magnesium Alloy Tube AZ31B AZ61A AZ91D Magnesium Alloy Pipe
Diameter :
0.5-5.0 mm
Color :
Silver Grey
Usage :
Welding
Chemical Composition :
Magnesium alloy
Description

High Purity Magnesium Alloy Tube AZ31B AZ61A AZ91D Magnesium Alloy Pipe

Details of Magnesium Alloy Tube:

Medium -small Size Magnesium Alloy Tube & Pipe
Variety
Alloy
Temper
Size(mm)
Adopted Standard
Diameter
Wall thickness
Thin-wall pipe
1x,3x,5x series
O,H14,H34,H32
6~130
0.5~5
GB/T6893
2x6x7x series
O,T4,T6
6~130
0.5~5
GB/T6893
Thick-wall tube
1x,3x,5x,8x series
H112,O,F
20~180
5~40
GB/T4437.1 GJB2381
2x,6x,7x series
H112,T4,T6,O,F
20~180
5~40
GB4437 GB/T4437.1 GJB2381
Large Size Magnesium Alloy Tube
Variety
Alloy
Temper
Sizemm
Adopted Standard
Diameter
Wall thickness
Tube
1xseries,5A02,5A03,5A05,5A06,3A21,
2A11,2A12,6A02,7A04,7A09
H112
120~400
10~40
GB4437
2A11,2A12,6A02,5A06
O
120~280
10~35
2A11,2A12,6A02
T4
120~280
10~35
6A02,7A04,7A09
T6
120~280
10~35

High Purity Magnesium Alloy Tube AZ91D Pipe With Superior Corrosion Performance

Introduction of Magnesium Alloy Tube:

Magnesium is the lightest common structural metal with a density of 1.74g/cm3, in its solid state.

Magnesium is used in a wide variety of applications from medical and metallurgical to chemical and pyrotechnic . Magnesium alloy developments have traditionally been driven by aerospace industry requirements for lightweight materials to operate under increasingly demanding conditions. Magnesium alloys have always been attractive to designers due to their low density, only two thirds that of aluminum. This has been a major factor in the widespread use of magnesium alloy castings and wrought products.

A further requirement in recent years has been for superior corrosion performance, and dramatic improvements in this regard have been demonstrated for new magnesium alloys. Improvements in mechanical properties and corrosion resistance have led to greater interest in magnesium alloys for aerospace and other specialized applications, and alloys are now being specified on some famous projects.

Alloy Thickness(mm)

Tensile strength

Rm

(N/mm²)

Yield strength

Rp0.2

(N/mm²)

Elongation

(A%)

50mm
AZ31B 0.3-3.00 260 170 24.0
3.00-10.00 230 140 18.0

M2M

 0.80-3.00 190 110 6.0
3.00-5.00 180 100 5.0
5.0-10.00 170 90 5.0
AZ40M 0.50-3.00 280 180 17.0
3.00-5.00 260 160 14.0
AZ41M 0.80-3.00 290 190 17.0
3.00-5.00 270 170 17.0
ME20M 0.80-3.00 250 170 21.0
3.00-10.00 220 140
