Silver grey 99.95% Magnesium Alloy Plate 1200-1800mm Width
Silver grey 99.95% Magnesium Alloy Plate 1200-1800mm Width
Silver grey 99.95% Magnesium Alloy Plate 1200-1800mm Width
Silver grey 99.95% Magnesium Alloy Plate 1200-1800mm Width
Silver grey 99.95% Magnesium Alloy Plate 1200-1800mm Width
Silver grey 99.95% Magnesium Alloy Plate 1200-1800mm Width
Silver grey 99.95% Magnesium Alloy Plate 1200-1800mm Width
Silver grey 99.95% Magnesium Alloy Plate 1200-1800mm Width
Silver grey 99.95% Magnesium Alloy Plate 1200-1800mm Width
Silver grey 99.95% Magnesium Alloy Plate 1200-1800mm Width
Specifications
Brand Name :
DOME
Model Number :
DM004
Certification :
ISO9001,CE,SGS
Place of Origin :
Zhengzhou,China
MOQ :
10Pcs
Price :
USD10-30/KG
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
3-25 work days
Packaging Details :
In carton, wooden case
Shape :
Plate，Sheet
Application :
Industrial
Material :
Magnesium
Chemical composition :
Magnesium,Mg
Dimensions :
according to demand
Product name :
Magnesium Alloy Plate
Color :
Silver grey
Size :
Customers' Requirements
Purity :
99.9%
Standard :
ISO9001,CE,SGS
Alloy or not :
alloy
Type :
ZK60A AZ31B AZ61A AZ80A WE43B M1C MIA
Name :
Magnesium plate AZ59
Usage :
Used in alloying etc.
Description

Factory price 99.95% mg high pure magnesium oxide plate customized

Due to its good specifications, AZ31B magnesium alloy can be used in all kinds of field.
1. Magnesium alloy thick plate are used to make satellites, lunar landing aircraft bases, exterior panel of missile and rocket and the empennage of missile and plane.

2. Magnesium alloy middle board are used to make the auxiliary tank ,side board and other structure of battleplane.

3. Cast sheet of magnesium alloy:

  • The magnesium alloy are used on the train for vibration attenuation, seat and couchette framework lining board and goods shelf.
  • The wide width usually requests between 1200-1800mm,and thickness between 1 and 1.5mm on cars’ front and rear panels, door panels .
  • The shell of 3C product, computer, mobile hard disk, CD, camea, acoustics, cell phone.
  • Magnesium etching has replaced copper plate in printing and printing plate industry, and average thickness of the plate is 5mm.
  • Magnesium has been continuously used in electric tool and sport equipment.
Alloy Designation Mechanical Properties
New Code Old Code Thickness (mm) Tensile Strength Rm (N/mm²) Yield Strength Rp0.2 (N/mm²) Elongation (A%) 50mm
AZ31B 0.3-3.0 260 170 24.0
3.0-10.0 230 140 18.0
M2M MB1 0.80-3.00 190 110 6.0
3.00-5.00 180 100 5.0
5.00-10.00 170 90 5.0
AZ40M MB2 0.50-3.00 280 180 17.0
3.00-5.00 260 160 14.0
AZ41M MB3 0.80-3.00 290 190 17.0
3.00-5.00 270 170 14.0
ME20M MBB 0.80-3.00 250 170 21.0
3.00-10.00 220 140 15.0

Silver grey 99.95% Magnesium Alloy Plate 1200-1800mm Width
