Specifications
Brand Name :
DOME
Model Number :
DM004
Certification :
ISO9001,CE,SGS
Place of Origin :
Zhengzhou,China
MOQ :
10Pcs
Price :
USD10-30/KG
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
3-25 work days
Packaging Details :
In carton, wooden case
Shape :
Plate，Sheet
Application :
Industrial
Material :
Magnesium
Chemical composition :
Magnesium,Mg
Dimensions :
according to demand
Product name :
Magnesium Alloy Plate
Color :
Silver grey
Size :
Customers' Requirements
Purity :
99.9%
Standard :
ISO9001,CE,SGS
Alloy or not :
alloy
Type :
ZK60A AZ31B AZ61A AZ80A WE43B M1C MIA
Name :
Magnesium plate AZ59
Usage :
Used in alloying etc.
Description

Magnesium Alloy Plate Photoengraving Plate and Sheet AZ31 for hot stamping foils

Product Name
Professional Hot Rolled AZ31 ZK60 1Kg Magnesium Alloy Thicker Plate
Standard
AMS/ASTM/JIS/BS/ISO
Brand
AZ31B/ZK60A/AZ91D/AZ61A/AZ40M/AZ41M/AZ80A
Thickness
0.3mm-200mm
Width
customized Max.width 3000mm
Length
Customized
Application
transportation (automobiles, motorcycles, bicycles, rail transit, aviation); electronic products (computers, mobile phones,
digital cameras, etc.); medical equipment (wheelchairs, crutches, rehabilitation fitness equipment, etc.) aerospace; textile High
standards and diversified demands in the fields of printing machinery and automobiles.
Lead time
3 to 25 working days
Packing
Wooden pallet or according to customer's request
Specification of magnesium alloy:
Magnesium Alloy Plates/sheet
classify
specification
Brand
AZ31B/ZK60A/AZ91D/AZ61A/AZ40M/AZ41M/AZ80A
Sheet
Thickness:0.3-7.9mm Customized Max.width 600mm
Medium and heavy plate
Thickness:8-15mm Customized Max.width 1500mm
Thick plate
Thickness:15-200mm Customized Max.width 3000mm
Magnesium Alloy Bar/Rod
Brand
AZ31B/ZK60A/AZ91D/AZ61A/AZ40M/AZ41M/AZ80A/Mg99.95
Extrusion Bar
φ3-φ130*3000(Customized)
Cast round bar billet
φ93-φ600*4500(Customized)
Magnesium alloy profiles
Size
Customized
Chemical Composition Of Magnesium Alloy Plate/Sheet :
ASTM B107/B107-13
ASTM B93/B93M
AZ31B
ZK60A
AZ61A
AZ80A
Al %
2.50-3.50
--------
5.80-7.20
7.80-9.20
Ca %
0.04max
--------
--------
--------
Mn %
0.20-1.00
--------
0.15-0.50
0.12-0.50
Cu %
0.01max
--------
0.05max
0.05max
Fe %
0.005max
--------
0.005max
0.005max
Si %
0.10max
--------
0.10max
0.10max
Zn %
0.60-1.40
4.8-6.2
0.40-1.50
0.20-0.80
Ni %
0.005max
--------
0.005max
0.005max
Others each %
--------
--------
--------
--------
Others total%
0.30max
0.30max
0.30max
0.30max
Mg
BALANCE
BALANCE
BALANCE
BALANCE
Tensile requirements Of Magnesium Alloy Plate/Sheet :
Magnesium Alloy
Mechanical Property
Application
ASTM
tensile strength(N/MM2)
Yield strength(N/mm)
Elongation
--
AZ31B
230~290
170~210
10~24
Standard extrusion alloy
AZ61A
270~390
190~240
9~15
High strength extrusion alloy
AZ80A
330~360
230~250
8~10
High strength extrusion alloy
