Standard API 5CT Casing And Tubing L245MB/NB L290MB/NB L360 MB/NB Long Lifespan
Standard API 5CT Casing And Tubing L245MB/NB L290MB/NB L360 MB/NB Long Lifespan
Standard API 5CT Casing And Tubing L245MB/NB L290MB/NB L360 MB/NB Long Lifespan
Standard API 5CT Casing And Tubing L245MB/NB L290MB/NB L360 MB/NB Long Lifespan
Specifications
Brand Name :
Best
Model Number :
114.3 - 508 mm
Certification :
API
Place of Origin :
China
MOQ :
1 Tons
Price :
600 usd/ton
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100000Ton/Month
Delivery Time :
5-8 working days
Packaging Details :
bundle,,painting against corrosion, protective plastic caps, special packing can be offered by customer.
Standard :
API 5CT, API 5D
Grade :
K55, J55, L80-1 ,N80,C90,C95, P110, T95
Out diameter :
API J55, API K55, API L80,
Application :
Oil Pipe
Surface :
Copper Coated
Specification :
2 3/8"-4 1/2"*0.167"-0630"
Description

Product Name : OCTG (OLAJ ÉS GÁZIPARI, PETROKÉMIAI CSÖVEK), ÉGHETŐ ANYAGOK VEZETÉSÉRE
ALKALMAS CSÖVEK
OCTG azaz az un. éghető anyagok vezetésére alkalmas csöveket elsősorban olaj és gázipar számára forgalmazzuk,
csővezeték építéshez, szerelési és karbantartási munkákhoz hossz hegesztett és spirál hegesztett kivitelben. Ezen termékeket
kombinálni tudjuk csőszigeteléssel is.
Méretválaszték: Ø 21,3-3500 mm
Szabványok: EN 10208-1, EN 10208-2
Minőségek: L245MB/NB, L290MB/NB, L360 MB/NB, L290 NB/MB, L415 NB/MB, L210GA, L235GA, L245GA, L290GA,
L360GA
Hosszak: 4-13 (20) m

OCTG (OIL, GAS, PETROCHEMICAL TUBES), TUBES SUITABLE FOR CONDUCTING
COMBUSTIBLE MATERIALS
We deal with our OCTG tubes (so called tubes suitable for conducting flammable materials) mainly for the petrochemical
oil and gas industry for big and smaller line pipe, maintenance project sin spirally welded and longitudinally welded typs.
Thes eproducts can be cominated with isolation and coatings.
Size assortment: Ø 21,3-3500 mm
Standards: EN 10208-1, EN 10208-2
Qualities: L245MB/NB, L290MB/NB, L360 MB/NB, L290 NB/MB, L415 NB/MB, L210GA, L235GA, L245GA, L290GA, L360GA
Lenghts: 4-13 (20) m

API 5CT J55 oil casing seamless pipe Steel Grades: K55, J55, L80-1 ,N80,C90,C95, P110, T95

Standard: API 5CT, API 5D
Steel Grades: K55, J55, L80-1 ,N80,C90,C95, P110, T95
Size: 2 3/8"-4 1/2"*0.167"-0630"

Casing Pipe

Tubing steel pipe

Oil Casing Pipe/Steel Pipe

Including ordinary casing, Anti-collapse casing, Anti-corrosion casing, Hi-strength casing

Serves as walls of a well;

Standard: API 5CT

Steel Grades: k55, J55, L80,N80,C90,C95, P110 T95, M65,E75,X95,G105,S135

1) Tubing

OD: 2 3/8" -----4 1/2"

WT: 0.167" -----0.630"

Note: P : Plain end, N: Non upset, U: External upset, T&C: Threaded and coupled.

2) Casing

OD: 2 3/8“ ----20"

WT: 0.205" --- 0.5"

Note: P: Plain end, S: Short round thread, L: Long round thread

Length

R1 R2 R3

Tubing 6.10 -7.32 m 8.53-9.75m 11.58-12.80m

Casing 4.88 - 7.62m 6.72 -10.36m 10.36 - 14.63m

3) Drill Pipe

OD: 2 3/8" - 5 1/2"

WT: 0.280" - 0.449"

Note: EU: External upset , IEU: Internal & External upset

Thread of tool joint are right-hand or left hand

API Oil pipe, Casing pipe

Type

Label 1

(in)

Outside diameter

(mm)

Wall thickness

(mm)

 Grade Type of thread Length
Casing 4-1/2 114.30 5.21-8.56 H40-P110

STC

LC

BC

 4.88-13.5m
5 127.00 5.59-12.70 H40-P110
5-1/2 139.70 6.20-22.22 H40-P110
6-5/8 168.28 7.32-12.06 H40-P110
7 177.80 5.87-22.22 H40-P110
Oil pipe 2-3/8 60.32 4.24-8.53 H40-P110

NU

EU

 6.1-12.8m
2-7/8 73.02 5.51-11.18 H40-P110
3-1/2 88.90 5.49-13.46 H40-P110
4 101.60 5.74-15.49 H40-P110
4-1/2 114.30 6.88-16.00 H40-P110

Grade Yield Strength(Mpa) Tensile Strength(Mpa) Hardness
J55 379-522 >517
K55 379-552 >655
N80 552-758 >689
L80-1 552-655 >689 23-241
C90 621-724 >689 25.4-255
C95 655-758 >724
T95 655-758 >724 25.4-255
P110 758-965 >862

API 5CT J55 oil casing seamless pipe Pictures
