Specifications
Material :
C45
Standard :
EN1092-1 Type 01
Steel Number :
1.0503
Type :
EN1092 Flanges
Description

EN1092 C45 FORGED Steel Flange 1.0503 Steel forged flange Forged Steel Flanges b16.9

Grade : C45
Number: 1.0503
Classification: Non-alloy quality steel
Standard:
EN 10277-2: 2008 Bright steel products. Technical delivery conditions. Steels for general engineering purposes
EN 10083-2: 2006 Steels for quenching and tempering. Technical delivery conditions for non alloy steels
EN 10250-2: 2000 Open steel die forgings for general engineering purposes. Non-alloy quality and special steels

Chemical composition % of steel C45 (1.0503): EN 10277-2-2008
Cr + Mo + Ni = max 0.63
C Si Mn Ni P S Cr Mo
0.43 - 0.5 max 0.4 0.5 - 0.8 max 0.4 max 0.045 max 0.045 max 0.4 max 0.1


Mechanical properties of steel C45 (1.0503)
Nominal thickness (mm): to 16 16 - 100 100 - 250 250 - 500 500 - 1000
Rm - Tensile strength (MPa) (+N) 620 580 560 540 530
Nominal thickness (mm): 5 - 10 10 - 16 16 - 40 40 - 63 63 - 100
Rm - Tensile strength (MPa) (+C) 750-1050 710-1030 650-1000 630-900 580-850
Nominal thickness(mm): to 100 100 - 250 250 - 500 500 - 1000
Re - Upper yield strength (MPa) (+N) 305 275 240 230
Nominal thickness(mm): 5 - 10 10 - 16 16 - 40 40 - 63 63 - 100
Rp0.2 0.2% proof strength (MPa) (+C) 565 500 410 360 310

Nominal thickness (mm): 5 - 10 10 - 16 16 - 40 40 - 63 63 - 100
A - Min. elongation at fracture (%) (+C) 5 6 7 8 8

Nominal thickness (mm): to 16 16 - 100 100 - 250
A - Min. elongation Lo = 5,65 √ So (%) (+N) 14 16 16

Brinell hardness (HBW): (+S) 255
Brinell hardness (HBW): (+A) 207
Brinell hardness (HBW): (+SH) 172 - 242


Properties of steel C45 (1.0503)
Weldability: Due to the medium-high carbon content it can be welded with some precautions.
Hardenability: It has a low hardenability in water or oil; fit for surface hardening that gives this steel grade a high hardness of the hardened shell.


Equivalent grades of steel C45 (1.0503)
EU
EN		 USA
-		 Germany
DIN,WNr		 Japan
JIS		 France
AFNOR		 England
BS		 Italy
UNI		 Spain
UNE		 China
GB		 Sweden
SS		 Poland
PN		 Czechia
CSN		 Austria
ONORM		 Russia
GOST		 Inter
ISO
C45
1042
1045
Gr.1043
C45
S45C
AF65C45
C45
070M46
50HS
1C45
C45
C45k
45
1650
45
12050
C45SW
45
C45
