Specifications
Material :
C22.8
Steel Number :
1.0460
Flange :
welding neck flanges
face :
RF, FF
Description

1.0460 Welding neck flanges C22.8 Weld neck flanges P250GH Steel Welding neck flanges

  • according to
  • EN1092-1 typ 11
  • DIN 2631; DIN 2632; DIN 2633; DIN 2634; DIN 2635; DIN 2636; DIN 2637; DIN 2638
  • ANSI B16.5

Delivered In Dimensions

  • DN 15 – DN 1600
  • pressure PN 6 – PN 250
  • Most of dimensions in material P245GH/P250GH and A105 available from stock. Non-stock flanges will be offered as soon as possible.
Grade : P250GH
Number: 1.0460
Classification: Non-alloy quality steel
Density: 7.85 g/cm ³
Standard:
EN 10273: 2007 Hot rolled weldable steel bars for pressure purposes with specified elevated temperature properties

Chemical composition % of steel P250GH (1.0460): EN 10273-2000
C Si Mn Ni P S Cr V Nb Ti Al -
0.18 - 0.23 max 0.4 0.3 - 0.9 max 0.3 max 0.025 max 0.015 max 0.3 max 0.02 max 0.01 max 0.03 0.015 - 0.05 Cr+Cu+Mo+Ni < 0.7


Mechanical properties of steel P250GH (1.0460)
Nominal thickness (mm): to 150
Rm - Tensile strength (MPa) (+N) 410-540
Nominal thickness (mm): to 50 50 - 100 100 - 150
ReH - Minimum yield strength (MPa) (+N) 250 240 230
KV - Impact energy (J) longitud., +20°
47
Nominal thickness (mm): to 150
A - Min. elongation at fracture (%) (+N) 25
