Specifications
Material :
P275nl1 P275NL2 P215nl P265nl
Type :
seamless steel pipes
Standard :
EN10216
Steel number :
1.0451
Description

En 10216-3 Grade P275nl1 P275NL2 P215nl P265nl Seamless Steel Pipes 1.0451 Steel Pipes

P275NL steel tube Specification
OD: φ4-410 mm
Wall thickness: 1-35 mm .

EN 10216-3 Grade P275NL1 Specification
EN Specification alloy steel Tubes are used for high temperature service applications.Seamless Alloy Steel Tubes according to EN 10216-3 Grade P275NL1 are reheated and furnished in full annlealed,isothermal annealed or normalised quenched and tempered condition .EN 10216-3 Grade P275NL Alloy Steel Seamless Tubes have a typical chemistry with additions of max 0.30 Chromium and max 0.10 Molybdenum.Bearing minimum tensile strength of 560 Mpa and maximum tensile strength530 Mpa, EN 10216-3 Grade P275NL Tubes have a minimum yield strength of 275 Mpa.

EN 10216-3 Grade P275NL1 Properties

Chemical Properties

Carbon Silicon Manganese Phosphorous Sulphur Molybdenum Nickel Chromium Copper Others
max 0.16 max 0.40 0.50-1.50 0.025 0.008 max 0.08 max 0.50 max 0.30 max 0.30 V max 0.05 Nb max 0.05 Ti max 0.04 Al min 0.020 Nb+Ti+V max 0.05

Mechanical Properties

Yield Strength Tensile Strength Elongation A5 min
MPa min ksi min MPa min MPa min ksi min Percentage
390 530 - 24


Equivalent Designation

DIN EN BS NFA ASTM ASME
DIN 17179 Grade FGP 28 T EN 10216-3 Grade P275NL1 NFA A49-2452) Grade TS 42-BT ASTM A 662 Grade B ASME SA 662 Grade B -

EN 10216-3 Grade P460N specification covers Alloy fine grain steel, pressure purposes. Pipe will be supplied in 5-7 metre random lengths with butt-weld ends and varnished to avoid oxidation of the steel when in storage. All pipes are fully certified and traceable with heat numbers hard stamped onto each random length. KINGMETAL Pipe can supply cut lengths; long pieces and even bore from forged, machined bar to satisfy your urgent demand.
More seamless steel pipe grade and standard we can offer :

Standard steel grade standard name Diemension Range
EN 10208 L210GA,L235GA,L245GA,L290GA,L360GA,
L245GA,L290NB,L260NB,L415NB,L360QNB,
LI150QB,L450QB,L485QB,L555QB		 Steel pipe fir pipelines for cumbustible Fluids 33.7-914mm
EN10210 S235JRH,S275JOH,S275J2H,S355JOH,
S355J2H,S355K2H,S375NH,S25NLH,
S355NH,S355NLH,S420NH,S420NLH,
S461NH,S460NLH		 Hot finished ,structural hollow sections of Non-alloy and tube
Grain steels		 10.2-711mm
EN10216-1 P195TRI,T195TR2,P235TR1,P235TR2,
P265TRI,P265TR2		 seamless steel tubes for pressure purpose 1 : Non-alloy steel 10.2-711mm
EN10216-2 P195GH, P235GH, P265GH, 20MnNb6,16Mo3,
8MoB5-4, 14Mov6.3, 10CrMo5.5, 13CrMo4-5,
10CrMo9-10, 11Cr9.10, 15NiCuMoNB-6-4, X11CrMo5+1, X11CrMo5+NTI,
X11CrMo5+NT2, X11CrMo9.1+1,
X11CrMo9.1+NT, X10CrMoVNb9-1,
X20CrNiV11-1		 seamless steel tubes for pressure purpose 2 : Non-alloy steel and alloy steel ,Tubes with specified elevated Temperature Properties 10.2-711mm
EN10216-3 P275NL1,P275NL2,P355N,P355BH,P355NL,
P355NL2,P460N,P460NH,P460NL1,P460NL2,
P620Q,P620QH,P690Q,P690QH,P690QL1,
P690QL2		 seamless steel tubes for pressure purpose 3 : alloy fine Grant stee Tubes 10.2-711mm
