1.8850 Slip On Plate Flanges S460MLH On Plate Flanges En1092 For Heavy Duty Applications
1.8850 Slip On Plate Flanges S460MLH On Plate Flanges En1092 For Heavy Duty Applications
1.8850 Slip On Plate Flanges S460MLH On Plate Flanges En1092 For Heavy Duty Applications
1.8850 Slip On Plate Flanges S460MLH On Plate Flanges En1092 For Heavy Duty Applications
1.8850 Slip On Plate Flanges S460MLH On Plate Flanges En1092 For Heavy Duty Applications
1.8850 Slip On Plate Flanges S460MLH On Plate Flanges En1092 For Heavy Duty Applications
1.8850 Slip On Plate Flanges S460MLH On Plate Flanges En1092 For Heavy Duty Applications
1.8850 Slip On Plate Flanges S460MLH On Plate Flanges En1092 For Heavy Duty Applications
Specifications
Material :
1.8850
Steel material :
S460MLH
Stanard :
en1092
flanges :
slip on plate flanges
Description
Grade : S460MLH
Number: 1.8850
Classification: Structural steel
Standard:
EN 10219-1: 2006 Cold formed welded structural hollow sections of non-alloy and fine grain steels. Technical delivery requirements


Chemical composition % of steel S460MLH (1.8850): EN 10219-1-2006
C Si Mn Ni P S Mo V N Nb Ti Al -
max 0.16 max 0.6 max 1.7 max 0.3 max 0.03 max 0.025 max 0.2 max 0.12 max 0.025 max 0.05 max 0.05 max 0.02 Cr+Cu+Mo < 0.6


Mechanical properties of steel S460MLH (1.8850)
Nominal thickness (mm): to 40
Rm - Tensile strength (MPa) 530-720
Nominal thickness (mm): to 16 16 - 40
ReH - Minimum yield strength (MPa) 460 440
KV - Impact energy (J) -50°
27
Nominal thickness (mm): to 40
A - Min. elongation at fracture (%) 17

Mechanical properties
ReH Minimum yield strength / Mindestwert der oberen Streckgrenze / Limite d elasticite minimale
Rm Tensile strength / Zugfestigkeit / Resistance a la traction
A Minimum elongation / Mindestwert der Bruchdehnung / Allongement minimal
J Notch impact test / Kerbschlagbiegeversuch / Essai de flexion par choc


Heat treatment conditions
+A Soft annealed
+AC Annealed to achieve spheroidization of the carbides
+AR As rolled
+AT Solution annealed
+C Cold drawn / hard
+CR Cold rolled
+FP Treated to ferrite-pearlite structure and hardness range
+I Isothermal annealing
+LC Cold drawn / soft
+M Thermo mechanical rolling
+N Normalized
+NT Normalized and tempered
+P Precipitation hardened
+PE Peeled
+QA Air quenched and tempered
+QL Liquid quenched and tempered
+QT Quenched and tempered
+S Treated to improve shearability
+SH As rolled and turned
+SR Cold drawn and stress relieved
+T Tempered
+TH Treated to hardness range
+WW Warm worked
+U Untreated
Structural steel
Chemical composition of steel S460MLH (1.8850), Standards of steel S460MLH (1.8850)
Mechanical Properties of steel S460MLH (1.8850)
steel S460MLH (1.8850) Tensile Strength, Elongation, Proof strength , Hardness
