Industry Furnace Fecral Wire 0cr23al5 1.35 Resistivity Wire / Strip / Rod / Bar
Industry Furnace Fecral Wire 0cr23al5 1.35 Resistivity Wire / Strip / Rod / Bar
Industry Furnace Fecral Wire 0cr23al5 1.35 Resistivity Wire / Strip / Rod / Bar
Industry Furnace Fecral Wire 0cr23al5 1.35 Resistivity Wire / Strip / Rod / Bar
Industry Furnace Fecral Wire 0cr23al5 1.35 Resistivity Wire / Strip / Rod / Bar
Industry Furnace Fecral Wire 0cr23al5 1.35 Resistivity Wire / Strip / Rod / Bar
Industry Furnace Fecral Wire 0cr23al5 1.35 Resistivity Wire / Strip / Rod / Bar
Industry Furnace Fecral Wire 0cr23al5 1.35 Resistivity Wire / Strip / Rod / Bar
Specifications
Brand Name :
TANKII
Model Number :
0Cr23Al5
Certification :
ISO9001:2008
Place of Origin :
Shanghai, China
MOQ :
20 kg
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
2000+TON+YEAR
Delivery Time :
7-12 DAYS
Packaging Details :
Spool with plastic film, coil, carton wooden case
Color :
Silver grey
Material :
Ferro Chromium Alumnium
Resistivity :
1.35
Density :
7.25 g/cm3
Conductor :
Solid
Condition :
Soft, half hard, hard
Description

Industry Furnace Fecral Wire 0cr23al5 1.35 Resistivity Wire / Strip / Rod / Bar

1)Alloy grades:
OCr21Al4, OCr21Al6, OCr25Al5, OCr23Al5, 1Cr13Al4, OCr21Al6Nb, Cr15Ni60, Cr20Ni80, Cr30Ni70, Cr20Ni30 etc.
We are the greatest professional manufacturers of resistance heating alloys in China, specializing in Ferro-Chrome Alloys (Ferritic Alloys), Nickel-Chrome Alloys (Nichrome alloys), Copper Nickel Alloys (Constantan Alloys)
In the form of wire, ribbon/strip:
Round Wire: Dia 0.04mm-8.0mm
Ribbon/strip: Thickness: 0.04mm-0.75mm
Width: 0.08mm-6.0mm

2)Fisical Property

Max continuous work temperature: 1250℃

Resistivity 20℃: 1.35±6%

Density: 7.25g/cm3

Thermal Conductivity at 20℃: 3.46

Linear Expansion Coeffcient 20-100℃: 15

Aproximate Melting Point: 1500

Tensile Strength: 630-780

Elogation: >12

Section Variation Shrink: 65-75

Hardess(H.B.): 200-260

Magnetic Property: Magnetic

Micrografic Structure: Ferrite

3)High quality assured:
Our works has a good command of advanced technological process in the respect of smelting, rolling, drawing and heat treatment up to finished products, together with the chemical analysis department, the physical testing department and the quality control department, we operate an all-round monitoring of our products from raw materials to final products.


4)Company Information

We can also supply other products by processing on your order: Stranded wire, twisted wire, coiled wire, wave-shaped wires and different kinds of standard or non-standard electrical heating element.
Shanghai TANKII ALLOY MATERIAL Co., Ltd.


Specification:

Alloy Type Diameter Resistivity Tensile Elongation
(%)		 Bending Max.
Continuous 		Working
Life
(mm) (μΩm)(20°C) Strength Times Service (hours)
(N/mm²) Temperature
(°C)
Cr20Ni80 <0.50 1.09±0.05 850-950 >20 >9 1200 >20000
0.50-3.0 1.13±0.05 850-950 >20 >9 1200 >20000
>3.0 1.14±0.05 850-950 >20 >9 1200 >20000
Cr30Ni70 <0.50 1.18±0.05 850-950 >20 >9 1250 >20000
≥0.50 1.20±0.05 850-950 >20 >9 1250 >20000
Cr15Ni60 <0.50 1.12±0.05 850-950 >20 >9 1125 >20000
≥0.50 1.15±0.05 850-950 >20 >9 1125 >20000
Cr20Ni35 <0.50 1.04±0.05 850-950 >20 >9 1100 >18000
≥0.50 1.06±0.05 850-950 >20 >9 1100 >18000
1Cr13Al4 0.03-12.0 1.25±0.08 588-735 >16 >6 950 >10000
0Cr15Al5 1.25±0.08 588-735 >16 >6 1000 >10000
0Cr25Al5 1.42±0.07 634-784 >12 >5 1300 >8000
0Cr23Al5 1.35±0.06 634-784 >12 >5 1250 >8000
0Cr21Al6 1.42±0.07 634-784 >12 >5 1300 >8000
1Cr20Al3 1.23±0.06 634-784 >12 >5 1100 >8000
0Cr21Al6Nb 1.45±0.07 634-784 >12 >5 1350 >8000
0Cr27Al7Mo2 0.03-12.0 1.53±0.07 686-784 >12 >5 1400 >8000


Industry Furnace Fecral Wire 0cr23al5 1.35 Resistivity Wire / Strip / Rod / BarIndustry Furnace Fecral Wire 0cr23al5 1.35 Resistivity Wire / Strip / Rod / Bar
