S Type Thermocouple Bare Wire PT And PT90+RH10 Couple Wire Dia 0.25mm
S Type Thermocouple Bare Wire PT And PT90+RH10 Couple Wire Dia 0.25mm
S Type Thermocouple Bare Wire PT And PT90+RH10 Couple Wire Dia 0.25mm
S Type Thermocouple Bare Wire PT And PT90+RH10 Couple Wire Dia 0.25mm
S Type Thermocouple Bare Wire PT And PT90+RH10 Couple Wire Dia 0.25mm
S Type Thermocouple Bare Wire PT And PT90+RH10 Couple Wire Dia 0.25mm
S Type Thermocouple Bare Wire PT And PT90+RH10 Couple Wire Dia 0.25mm
S Type Thermocouple Bare Wire PT And PT90+RH10 Couple Wire Dia 0.25mm
Specifications
Brand Name :
Tankii
Model Number :
B / R / S
Certification :
ISO9001
Place of Origin :
China
MOQ :
5 Meters
Price :
Negotiation
Payment Terms :
T/T, Paypal, Western Union, MoneyGram,
Supply Ability :
1000Ton per year
Delivery Time :
5 days
Packaging Details :
As the order quantity and customer requirement.
Material :
Pt-Rh
Surface :
Bright
Diameter :
0.1mm-5.0mm
Grade :
I/II
Item :
PT And PT90+RH10 Couple Wire Dia 0.25mm Used for S type Thermocouple
Description

PT And PT90+RH10 Couple Wire Dia 0.25mm Used for S type Thermocouple

Characteristics:

●Excellent thermoelectricity, excellent linear relationship between thermoelectrical potential and the temperature.

●Excellent thermoelectrical stability, high accuracy.

Platinum Rhodium Alloy S Type B Type R Type Thermocouple Wire 0.1mm 0.35mm 0.5mm With First Class

Quick Description

What is thermocouple wire?

Thermocouple wire allows temperatures to be measured electronically.

A typical thermocouple construction consists of a pair of dissimilar metals that are electrically joined together at the sensing point and connected to a voltage measuring instrument at the other end. When one junction is hotter than the other, a thermal “electromotive” force (in millivolts) is produced that is roughly proportional to the difference in temperature between the hot and cold junctions.

The thermocouple wires with different varieties and specifications of our company can be applied in all kinds of thermocouples, the temperature ranges from -270℃ to 1800℃.

The thermocouple wires have excellent performance and are extensively used in the temperature measurement and control in different fields, such as metallurgy, chemical industry, petroleum industry, machinery-electric industry, energy industry, agriculture and military industry.

Our products conform to the standards of IEC584 -1and IEC-2.

Please contact me if there is inquiry on thermocouple wire or cable.

Characteristics:

●Excellent thermoelectricity, excellent linear relationship between thermoelectrical potential and the temperature.

●Excellent thermoelectrical stability, high accuracy.

Application Range:
1. Heating – Gas burners for ovens
2. Cooling – Freezers
3. Engine protection – Temperatures and surface temperatures
4. High temperature control – Iron casting
Thermocouple Types and Temperature Range

Thermocouple type and index

Measurement Range

℃

Type

Index

PtRh30-PtRh6

 B 600~1700

PtRh13-Pt

 R 0~1600

PtRh10-Pt

 S 0~1600

NiCr-NiSi

 K -200~1300

NiCr-CuNi (constantan)

 E -200~900

Fe-CuNi (constantan)

 J -40~750

Cu-CuNi (constantan)

 T -200~350

NiCrSi-NiSi

 N -200~1300
Delivery and Packing:
1. Packaging Details : 500m/1000m per roll with plastic film wrapped and carton package.
2. Leading time : 5 - 7days, as the order quantity.
3. Delivery: By sea or air
Application:
S Type Thermocouple Bare Wire PT And PT90+RH10 Couple Wire Dia 0.25mm
