high resistance Nicr Alloy Strip NiCr 8020 Tape Bright annealed
high resistance Nicr Alloy Strip NiCr 8020 Tape Bright annealed
high resistance Nicr Alloy Strip NiCr 8020 Tape Bright annealed
high resistance Nicr Alloy Strip NiCr 8020 Tape Bright annealed
high resistance Nicr Alloy Strip NiCr 8020 Tape Bright annealed
high resistance Nicr Alloy Strip NiCr 8020 Tape Bright annealed
Specifications
Brand Name :
TANKII
Model Number :
NiCr80/20.
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
20kg
Price :
negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20, 000kg/month
Packaging Details :
spool+plastic bag+carton+pallet for resistance wires
color :
sliver or polish
Conductor Material :
Ni-Cr
thickness :
: 0.02----4.0mm
Condition :
Bright annealed
Feature: :
high nickel, high resistance
Certificate: :
ISO 9001 RoHS SGS
width :
2.5----250mm
type :
Nickel strip
Description

Nichrome Resistance Strip NiCr 80/20 Strip/tape/Sheet/Ribbon

Our company focus on nichrome striop/sheet/plaste production.

Grade: NiCr 30/20, NiCr 60/23, NiCr 60/15, NiCr 70/30, NiCr 80/20

ASTM B603, DIN 17470, JIS C2520, GB/T1234.

Our advantage:High quality,short delivery time,small MOQ.

Characteristics:Stable performance; Anti-oxidation; Corrosion resistance; High temperature stability; Excellent coil-forming ability; Uniform and beautiful surface condition without spots.

Usage:Resistance heating elements;Material in metallurgy;Household appliances;Mechanical manufacturing and other industries.

Chemical Composition

Properties/Grade Cr20Ni80 Cr30Ni70 Cr15Ni60 Cr20Ni35 Cr20Ni30
Main Chemical composition Ni Rest Rest 55.0-61.0 34.0-37.0 30.0-34.0
Cr 20.0-23.0 28.0-31.0 15.0-18.0 18.0-21.0 18.0-21.0
Fe ≤1.0 ≤1.0 Rest Rest Rest
Max. continuous service temp. of element 1200 1250 1150 1100 1100
Resistivity at 20oC (μΩ·m) 1.09 1.18 1.12 1.04 1.04
Density (g/cm3) 8.40 8.10 8.20 7.90 7.90
Thermal conductivity(KJ/m·h·oC) 60.3 45.2 45.2 43.8 43.8
Coefficient of lines expansion(α×10-6/oC) 18.0 17.0 17.0 19.0 19.0
Melting point (approx.)( oC) 1400 1380 1390 1390 1390
Elongation at rupture (%) >20 >20 >20 >20 >20
Micrographic structure austenite austenite austenite austenite austenite
Magnetic properties nonmagnetic nonmagnetic nonmagnetic nonmagnetic nonmagnetic
