Factory Bright Customized Diameter Length Cr20ni80 Ni80 Strong Nichrome Rod Bar With High Temperature Resistance
Factory Bright Customized Diameter Length Cr20ni80 Ni80 Strong Nichrome Rod Bar With High Temperature Resistance
Specifications
Brand Name :
Tankii
Model Number :
Nickel alloy wire
Certification :
ISO 9001
Place of Origin :
CHINA
MOQ :
15KG
Price :
25USD
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
2000kg/month
Delivery Time :
5-30 days
Packaging Details :
spool，coil
Grade :
NiCr Alloy
Application :
heating element and resistor
Condition :
Hard / Soft
Feature :
High Resistance
Material :
Ni80%Cr20%
Conductor Type :
solid
Resisivity :
1.09
Bar :
10-50mm
Composition :
Nickel, Chromium
Model No :
NCHW-1
Highest Temperature :
1200℃
Shipping Form :
by sir, air or by express
Type :
solid
Micrografic Structure :
Ferrite
Resistivity :
0.78+/-0.05
Available Forms :
Wire, strip, sheet, foil, bar, tube, powder
Usual Size :
0.523mm x 18 & 0.574mm
Max Working Temperature :
1200C
Description

Factory Bright Customized Diameter Length Cr20ni80 Ni80 Strong Nichrome Rod Bar with High Temperature Resistance

Ni80, also known as Nickel 80, is a high-performance nickel-chromium alloy renowned for its exceptional properties. Composed of 80% nickel and 20% chromium, this alloy offers numerous advantages in various industrial applications.

One of the key strengths of Ni80 is its remarkable resistance to high temperatures. It can withstand elevated heat levels without experiencing significant deformation or degradation, making it ideal for applications that involve intense heat or thermal cycling.

Additionally, Ni80 exhibits excellent corrosion resistance, ensuring its durability and longevity in corrosive environments. This attribute makes it highly suitable for applications exposed to moisture, chemicals, or other corrosive agents.

Another notable advantage of Ni80 is its exceptional oxidation resistance. It forms a protective oxide layer on its surface when exposed to air or high temperatures, enabling it to resist oxidation and maintain its integrity even in challenging conditions.

Furthermore, Ni80 possesses excellent electrical conductivity, making it highly desirable for applications requiring efficient electrical current flow. It is commonly used in heating elements, electrical resistors, and other electrical components where reliable performance and conductivity are paramount.

Overall, Ni80's combination of high-temperature resistance, corrosion resistance, oxidation resistance, and electrical conductivity makes it a versatile and reliable choice for a wide range of industrial applications.

Product Features

Grade Elongation Density (g/cm3) Electrical resistivity at 20℃(Ωmm2/m) Conductivity coefficient at 20℃ (WmK) Coefficient of Thermal Expansion x10-6/℃ Melting point (℃) Max continuous operating temperature in air (℃) Magnetic properties
(%)
Ni80Cr20 30 8.4 1.09 15 18 1400 1200 Non-magnetic
Ni35Cr20 35 7.9 1.04 13 19 1390 1100 Non-magnetic
Ni30Cr20 35 7.9 1.04 13 19 1390 1100 Non-magnetic
Ni60Cr15 35 8.2 1.12 13 17 1390 1150 Non-magnetic
Ni70Cr30 30 8.2 1.18 14 17 1380 1250 Non-magnetic
0Cr21Al4 16 7.35 1.23 13 13.5 1500 1100 Non-magnetic
1Cr13Al4 22 7.4 1.25 15 15.4 1450 950 Non-magnetic
0Cr23Al5 23 7.25 1.35 13 15 1500 1250 Non-magnetic
0Cr21Al6 20 7.16 1.42 13 14.7 1500 1250 Non-magnetic
0Cr25Al5 23 7.1 1.42 13 15 1500 1250 Non-magnetic
0Cr21Al6Nb 22 7.1 1.45 13 16 1510 1350 Non-magnetic
0Cr27Al7Mo2 20 7.1 1.53 13 16 1520 1400 Non-magnetic

Factory Bright Customized Diameter Length Cr20ni80 Ni80 Strong Nichrome Rod Bar With High Temperature ResistanceFactory Bright Customized Diameter Length Cr20ni80 Ni80 Strong Nichrome Rod Bar With High Temperature Resistance
