Color Enameled N4/N6/Ni200/Ni201 Reach 99.99% Pure Nickel Wire
Color Enameled N4/N6/Ni200/Ni201 Reach 99.99% Pure Nickel Wire
Color Enameled N4/N6/Ni200/Ni201 Reach 99.99% Pure Nickel Wire
Color Enameled N4/N6/Ni200/Ni201 Reach 99.99% Pure Nickel Wire
Color Enameled N4/N6/Ni200/Ni201 Reach 99.99% Pure Nickel Wire
Color Enameled N4/N6/Ni200/Ni201 Reach 99.99% Pure Nickel Wire
Color Enameled N4/N6/Ni200/Ni201 Reach 99.99% Pure Nickel Wire
Color Enameled N4/N6/Ni200/Ni201 Reach 99.99% Pure Nickel Wire
Specifications
Brand Name :
Tankii
Model Number :
N4/N6/Ni200/Ni201
Place of Origin :
China
MOQ :
20kg
Price :
USD+20USD/KG
Payment Terms :
T/T
Supply Ability :
10TON/MONTH
Delivery Time :
10days
Packaging Details :
Cardboard box
color :
RED, GREEN, BLUE, SILVER ETC.
Description

Basic Info.

Model NO.
Nickel 200
Conductor Material
Copper
Sheath Material
enameled
Insulation Material
Enameled
Material Shape
Round Wire
Range of Application
Cold-Resistant
Certification
ISO9001, CE, CCC, RoHS
Brand
China
Serves
Samll Order Accepted
diameter
0.02-1.5mm
color
RED, GREEN, BLUE, SILVER ETC.
Temperature
130/155/180/200/220/240
Purity
99.6%
Surface
Bright
sample
accepted
density
8.9 g/cm3
Transport Package
in Spool
Specification
0.02-1.5mm
Trademark
TANKII
Origin
China
HS Code
75061000
Production Capacity
2000 Tons/Year

Product Description

Color Enameled N4/N6/Ni200/Ni201 Reach 99.99% Pure Nickel Wire

Product Description
These enameled resistance wires have been broadly used for standard resistors, automobile
parts, winding resistors, etc. using the insulation processing best suited for these applications, taking full advantage of the distinctive features of enamel coating.
Furthermore, we will carry out enamel coating insulation of precious metal wire such as silver and platinum wire upon order. Please make use of this production-on-order.

Type of bare Alloy wire
The alloy we can do enamelled are Copper-nickel alloy wire,Constantan wire,Manganin wire. Kama Wire,NiCr Alloy wire,FeCrAl Alloy wire etc alloy wire
Size:
Round wire:0.018mm~3.0mm
Color of enamel insulation:Red,Green,Yellow,Black,Blue,Nature etc.
Ribbon Size:0.01mm*0.2mm~1.2mm*24mm
Moq:5kg each size

Type of insulation
Insulation-enamelled Name Thermal LevelºC
(working time 2000h)		 Code Name GB Code ANSI. TYPE
Polyurethane enamelled wire 130 UEW QA MW75C
Polyester enamelled wire 155 PEW QZ MW5C
Polyester-imide enamelled wire 180 EIW QZY MW30C
Polyester-imide and polyamide-imide double coated enameled wire 200 EIWH
(DFWF)		 QZY/XY MW35C
Polyamide-imide enamelled wire 220 AIW QXY MW81C



Color Enameled N4/N6/Ni200/Ni201 Reach 99.99% Pure Nickel Wire
Color Enameled N4/N6/Ni200/Ni201 Reach 99.99% Pure Nickel WireColor Enameled N4/N6/Ni200/Ni201 Reach 99.99% Pure Nickel Wire
