0.1mm 0.6mm High Elastic Modulus Elastic Alloy 3j53 Wire For Optical And Electronic Components
0.1mm 0.6mm High Elastic Modulus Elastic Alloy 3j53 Wire For Optical And Electronic Components
0.1mm 0.6mm High Elastic Modulus Elastic Alloy 3j53 Wire For Optical And Electronic Components
0.1mm 0.6mm High Elastic Modulus Elastic Alloy 3j53 Wire For Optical And Electronic Components
0.1mm 0.6mm High Elastic Modulus Elastic Alloy 3j53 Wire For Optical And Electronic Components
0.1mm 0.6mm High Elastic Modulus Elastic Alloy 3j53 Wire For Optical And Electronic Components
0.1mm 0.6mm High Elastic Modulus Elastic Alloy 3j53 Wire For Optical And Electronic Components
0.1mm 0.6mm High Elastic Modulus Elastic Alloy 3j53 Wire For Optical And Electronic Components
Specifications
Brand Name :
Tankii
Model Number :
3J53
Certification :
ISO9001
Place of Origin :
China Mainland
MOQ :
10kg
Price :
Negotiation
Payment Terms :
T/T, Paypal, Western Union, MoneyGram,
Supply Ability :
1000Ton per year
Delivery Time :
20 days after getting the payment
Packaging Details :
Standard exoprt package in carton box or wooden box
Item :
0.1mm 0.6mm High Elastic Modulus Elastic Alloy 3j53 Wire For Optical And Electronic Components
Material :
nickel alloy wire
Surface :
Bright
Diameter :
0.1mm
Wire Type :
Single wire
Application :
in medical devices, robotics, aerospace, and automotive industries
MOQ :
10kg
Description

0.1mm 0.6mm High Elastic Modulus Elastic Alloy 3j53 Wire For Optical And Electronic Components

In the large family of metal materials, elastic alloys play an important role in multiple fields due to their unique properties.

Among them, 3J53, as a high-performance elastic alloy steel strip and wire material, has become an indispensable material in the fields of aerospace, precision instruments, medical equipment, etc. due to its excellent elasticity, corrosion resistance, and processing performance.

The 3J53 elastic alloy steel strip is mainly composed of elements such as nickel (Ni), iron (Fe), chromium (Cr), titanium (Ti), etc. The nickel content dominates, endowing the alloy with excellent elasticity and corrosion resistance. At the same time, the addition of chromium improves the oxidation resistance and corrosion resistance of the alloy, while the addition of titanium helps to enhance the stability and strength of the alloy. In addition, the alloy also contains a small amount of elements such as carbon (C), manganese (Mn), silicon (Si), phosphorus (P), and sulfur (S). The precise ratio of these elements gives the 3J53 alloy steel strip unique properties.

Main applications of 3j53 wire/ strip:

1. Manufacturing of springs and leaf springs: The high elastic modulus and good resilience of 3J53 precision alloy wire make it an ideal material for manufacturing high-strength and high stability springs and leaf springs. These springs and leaf springs are widely used in fields such as automotive, aerospace, and mechanical engineering.
2. Medical Devices : By utilizing its shape memory ability and biocompatibility, 3J53 can be used to make medical devices such as cardiovascular stents and orthotics, providing important technical support for the medical field.
3. Optical and Electronic Devices: The high elastic modulus and good conductivity of 3J53 make it an ideal material for manufacturing optical and electronic devices, such as elastic connectors, electrical connectors, conductive elastic sheets, etc.

Chemical compostion:

Ni Cr Ti Al C Mn Si P S Fe
41.5~43 5.2~5.8 2.3-2.7 0.5-0.8 ≤0.05 ≤0.8 ≤0.8 ≤0.02 ≤0.02 Bal.

The production process of 3J53 precision alloy wire mainly includes steps such as melting, casting, heat treatment, cold processing, and hot processing. During the melting process, it is necessary to strictly control the composition of raw materials and melting temperature to ensure the purity and uniformity of the alloy. The casting process produces alloy ingots through mold forming. Subsequently, the microstructure and properties of the alloy were adjusted through heat treatment. Finally, the alloy ingot is processed into the required wire material through processes such as cold working and hot working. During the processing, it is necessary to strictly control the processing parameters and process conditions to ensure the quality and performance of the wire material.

Application:

0.1mm 0.6mm High Elastic Modulus Elastic Alloy 3j53 Wire For Optical And Electronic Components

0.1mm 0.6mm High Elastic Modulus Elastic Alloy 3j53 Wire For Optical And Electronic Components

0.1mm 0.6mm High Elastic Modulus Elastic Alloy 3j53 Wire For Optical And Electronic Components

Vascular stent:

0.1mm 0.6mm High Elastic Modulus Elastic Alloy 3j53 Wire For Optical And Electronic Components

Delivery and Packing of thermocouple wire:
1. Packaging Details : 5kg or 10kg per roll with plastic film wrapped and carton package.
2. Leading time : 5 - 20 days, as the order quantity .
3. Delivery: By express, air, sea as per qty
Welcome to call us or email to us for more information on this product.
