Highly Reflective 3003 H22 Aluminium Checker Plate Sheet Aluminum Tread Plate Good Slip Resistance
Highly Reflective 3003 H22 Aluminium Checker Plate Sheet Aluminum Tread Plate Good Slip Resistance
Highly Reflective 3003 H22 Aluminium Checker Plate Sheet Aluminum Tread Plate Good Slip Resistance
Highly Reflective 3003 H22 Aluminium Checker Plate Sheet Aluminum Tread Plate Good Slip Resistance
Highly Reflective 3003 H22 Aluminium Checker Plate Sheet Aluminum Tread Plate Good Slip Resistance
Highly Reflective 3003 H22 Aluminium Checker Plate Sheet Aluminum Tread Plate Good Slip Resistance
Highly Reflective 3003 H22 Aluminium Checker Plate Sheet Aluminum Tread Plate Good Slip Resistance
Highly Reflective 3003 H22 Aluminium Checker Plate Sheet Aluminum Tread Plate Good Slip Resistance
Specifications
Brand Name :
HUANYU
Model Number :
HYTP3003H22
Place of Origin :
CHINA
MOQ :
1 metric ton
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
120 metric tons per month
Delivery Time :
21 days
Packaging Details :
plywood case
Slip Resistance :
Good
Forming Ability :
Good
Drilling Ability :
Good
Weldability :
Good
Surface Treatment :
Highly Reflective
Applications :
flooring, loading ramps, trench covers, dock flooring, stair treads, elevator floors, freezers floors, etc.
Description
Highly Reflective, Economical 3003 H22 Aluminum Sheet Plate Aluminum Tread Plate With Good Slip Resistance

Having good forming, drilling and welding ability, 3003 H22 Aluminum Diamond Plate is easy to fabricate and its raised diamond lug pattern provides good slip resistance.

Fire Truck Quality Diamond Plate which has grooves etched in the top of the diamond for added traction.
3003 H22 Aluminum Diamond Plate, Aluminum Tread Plate, this highly reflective, economical product is widely used in decorative, cosmetic and architectural applications.
Aluminum Diamond Plate is widely used for industrial applications - flooring, loading ramps, trench covers, dock flooring, stair treads, elevator floors, freezers floors, etc.

3003 Chemical Composition Limits
Weight% Al Cu Si Fe Mn Zn Others
3003 Rem 0.05-0.20 0.60 max 0.70 max 1.0-1.5 0.10 max 0.05 each
0.15 total

Typical Mechanical Properties

Material Condition Tensile Strength (ksi min) Yield Strength (ksi min) Elongation % in 2" 0.064 Sheet Min 90° Cold Bend Radius for 0.064" Thick
3003-0 Sheet 0.064" thick 3003-0 14-19 5 25 0
3003-H12 Sheet 0.064" thick 3003-H12 17-23 12 6 0
3003-H14 Sheet 0.064" thick 3003-H14 20-26 17 5 0
3003-H16 Sheet 0.064" thick 3003-H16 24-30 21 4 1/2 - 1 1/2 T
3003- Sheet 0.064" thick 3003-H18 27 min 24 4 1 1/2 -3T
