Professional 3003 Aluminum Sheet Plate Excellent Corrosion Resistance
Professional 3003 Aluminum Sheet Plate Excellent Corrosion Resistance
Professional 3003 Aluminum Sheet Plate Excellent Corrosion Resistance
Professional 3003 Aluminum Sheet Plate Excellent Corrosion Resistance
Professional 3003 Aluminum Sheet Plate Excellent Corrosion Resistance
Professional 3003 Aluminum Sheet Plate Excellent Corrosion Resistance
Professional 3003 Aluminum Sheet Plate Excellent Corrosion Resistance
Professional 3003 Aluminum Sheet Plate Excellent Corrosion Resistance
Specifications
Brand Name :
HUANYU
Model Number :
HYAP3003
Place of Origin :
CHINA
MOQ :
1 metric ton
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
110 metric tons per month
Delivery Time :
7 dyas
Packaging Details :
plywood case
Applications :
aircraft fittings,
Machinability :
Good
Corrosion Resistance :
Excellent
Workability :
Excellent
Utility :
Chemical equipment, Cooking and Kitchen equipment, decorative trim and storage tanks
Description

3003 Aluminum Sheet Plate With Excellent Corrosion Resistance And Workability

Aluminum Alloy 3003

is a popular alloy that offers customers very good atmospheric corrosion resistance and moderate strength. Aluminum 3003 offers good machinability for aluminum alloys, though it is not heat treatable. 3003 is weldable by conventional welding methods.

Aluminum 3003 is a commercially pure aluminum with the addition of manganese. 3003 is the most widely used aluminum alloy due to it's excellent characteristics.

3003 Aluminum Sheet Plate applications :

  • Chemical equipment
  • Ductwork
  • Cooking utensils
  • Pressure vessels
  • Eyelet stock
  • Ice cube trays
  • Garage doors
  • Refrigerator panels
  • Gas line and tanks
  • Heat exchangers
  • Drawn and spun parts
  • Roofing, sidings, acoustic ceilings, and corrugated sheets
3003 Aluminum Chemical Composition Limits
Weight% Al Cu Si Fe Mn Zn Others
3003 Rem 0.05-0.20 0.60 max 0.70 max 1.0-1.5 0.10 max 0.05 each
0.15 total

Typical Mechanical Properties

Material Condition Tensile Strength (ksi min) Yield Strength (ksi min) Elongation % in 2" 0.064 Sheet Min 90° Cold Bend Radius for 0.064" Thick
3003-0 Sheet 0.064" thick 3003-0 14-19 5 25 0
3003-H12 Sheet 0.064" thick 3003-H12 17-23 12 6 0
3003-H14 Sheet 0.064" thick 3003-H14 20-26 17 5 0
3003-H16 Sheet 0.064" thick 3003-H16 24-30 21 4 1/2 - 1 1/2 T
3003- Sheet 0.064" thick 3003-H18 27 min 24 4

1 1/2 -3T
