Custom 7075 T651 Aluminum Sheet Plate 50mm Thickness High Strength
Custom 7075 T651 Aluminum Sheet Plate 50mm Thickness High Strength
Custom 7075 T651 Aluminum Sheet Plate 50mm Thickness High Strength
Custom 7075 T651 Aluminum Sheet Plate 50mm Thickness High Strength
Custom 7075 T651 Aluminum Sheet Plate 50mm Thickness High Strength
Custom 7075 T651 Aluminum Sheet Plate 50mm Thickness High Strength
Specifications
Brand Name :
HUANYU
Model Number :
HYAP7075T651
Place of Origin :
CHINA
MOQ :
1 metric ton
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
140 metric tons per month
Delivery Time :
7 days
Packaging Details :
plywood case
Thickness :
50mm
Nominal Density (68° F / 20°C) :
2.80 g/c.c.
Melting Range :
532°C - 635 °C
Specific Heat (212 °F / 100°C :
960 J/kg-°K
Tensile Strength (ksi) :
78000 psi
Yield Strength (ksi) :
68000 psi
Elongation % :
7%
Applications :
Aircraft And Ordnance Industries, aircraft fittings, missile parts, regulating valve parts, meter gears, fuse parts, worm gears and keys.
weight-to-strength ration :
Excellent
Formability :
Great
Description
Custom 7075 T651 Aluminum Sheet Plate 50mm Thickness High Strength
7075 Aluminium Alloy Sheet Plate
offers the highest strength of the common screw machine alloys.
The T6 and T651 tempers have fair machinability. Alloy 7075 is heavily utilized by the aircraft and ordnance industries because of its superior strength.
7075 Alloy Chemical Composition Limits
Weight% Al Si Fe Cu Mn Mg Cr Zn Ti Other Each Others Total
7075 min Rem - - 1.2 - 2.1 0.18 5.1 - - -
7075 max Rem 0.40 0.50 2.0 0.30 2.9 0.28 6.1 0.20 0.05 0.15

7075 Aluminum Sheet Plate Typical Mechanical Properties

Material Temper Thickness (in) Tensile Strength (ksi) Yield Strength (ksi) Elongation %
Alloy 7075 Sheet T6 Bare 0.125 - 0.25 78 69 8
Alloy 7075 Sheet T651 Bare 0.25 - 0.50 78 67 9
Alloy 7075 Sheet T651 Bare 0.5 - 1.0 78 68 7
Alloy 7075 Sheet T6 Clad 0.188 - 0.25 75 64 8
Alloy 7075 Sheet T651 Clad 0.25 - 0.50 75 65 9
Alloy 7075 Sheet T651 Clad 0.5 - 1.00 78 68 7

7075 Aluminum Typical Physical Properties

Characteristic English Metric
Nominal Density (68° F / 20°C) 0.101 lbs./ in ³ 2.80 Mg/m³
Melting Range 990° F - 1175° F 532°C - 635 °C
Specific Heat (212 °F / 100°C 0.23 BTU/lb - °F 960 J/kg-°K

Custom 7075 T651 Aluminum Sheet Plate 50mm Thickness High StrengthCustom 7075 T651 Aluminum Sheet Plate 50mm Thickness High StrengthCustom 7075 T651 Aluminum Sheet Plate 50mm Thickness High Strength
