Professional 6063 T6 T Profile Aluminium Extrusion For Constructional Wall
Professional 6063 T6 T Profile Aluminium Extrusion For Constructional Wall
Specifications
Brand Name :
HUANYU
Model Number :
HYAP6063T6
Place of Origin :
CHINA
MOQ :
5 METRIC TONS
Price :
NEGOTIABLE
Payment Terms :
T/T
Supply Ability :
35 METRIC TONS PER MONTH
Delivery Time :
40 days
Packaging Details :
PALLET
Wall Thickness :
19.6mm
Density :
2.7 g/cc
Ultimate Tensile Strength :
186 MPa
Yield Tensile Strength :
145 MPa
Melting Point :
616-654 Celsius Degree
Elongation at Break Percentage :
18%
Shape :
Square
Description

High Strength 6063 T6 Extruded Profiles Used As Constructional Wall

6063 is often called architectural aluminum for two reasons. First, it has a surface finish that is far smoother than the other commercially available alloys. Second, its strength is significantly less than most other aluminum alloys.

Specifications on High Strength 6063 T6 Extruded Profiles Used As Constructional Wall

Wall Thickness: 19.60mm

Length X Width = 237mm x 180mm

Height: 3980mm

6063 Typical Chemical Composition %
Weight % Si Fe Cu Mn Mg Cr Zn Ti Each Total
Minimum 0.20 0.45
Maximum 0.60 0.35 0.10 0.10 0.90 0.10 0.10 0.10 0.05 0.15

Remainder Aluminum

6063 Typical Mechanical Properties
Temper Tensile Hardness
Ultimate Yield Elongation Brinell
KSI MPA KSI MPA %
T5, T52 27 186 21 145 12 60
T6 35 241 31 214 12 73
