Semi - Rigid Aluminium Food Containers Alloy 8011-O Thickness 0.045-0.12 mm
Semi - Rigid Aluminium Food Containers Alloy 8011-O Thickness 0.045-0.12 mm
Semi - Rigid Aluminium Food Containers Alloy 8011-O Thickness 0.045-0.12 mm
Semi - Rigid Aluminium Food Containers Alloy 8011-O Thickness 0.045-0.12 mm
Specifications
Brand Name :
Tai Lian
Certification :
ISO9001, ISO14001
Place of Origin :
China
MOQ :
3ton
Price :
negotiation
Payment Terms :
T/T, L/C, DP
Supply Ability :
600000 per years
Delivery Time :
10-30 days
Packaging Details :
Strong sea-worthy export package
Alloy :
8001
Temper :
O
Application :
Food container used on plane,fast food utensile
Thickness :
0.001-0.02mm
Width(mm) :
150-1250mm
Type :
Roll
Description

Semi-Rigid Container Foil Thickness 0.045-0.12mm ALLOY 8011-O for food Container

Aluminum Foil for Food--including food packaging and food container:

Product Name Application Alloy Temper Thickness Width
Container Foil Food Container 3003/8011 O/H22/
H24		 0.045mm
- 0.12mm		 150mm -
1300mm
Household Aluminum Foil Food packing 1235/8011 O 0.009mm
- 0.024mm		 150mm -
1250mm

Aluminum Foil for Packaging--wide application:

Product Name Application Alloy Temper Thickness Width
Beer bottle mark Foil Beer bottle mark 8011 O 0.010mm 150mm -
1250mm
Pharmaceutical Foil Packing for Medicine 8011 H18/O 0.018mm
- 0.03mm		 150mm -
1250mm
Package, converting Foil Soft packing 8011 O 0.006mm
-0.009mm		 150mm -
1250mm
Cigarette Foil Packing for Cigarette 1060/1070/
3003/8011		 O/H14/
H18/H24		 0.05mm
- 0.60mm		 5mm -
200mm

mechanical property:

Foil Classification Thickness(mm)
Alloy		 Thickness Tolerrance Width Tolerance
Thin Gauge
0.005-0.009		 0.005

1235

8011

8079

 ±5% (200-1880)±1
0.006
0.0065
0.007
0.008
0.009

Mechanical Performance		 Strengthen(Mpa) 50-160
(according to customer's requirements and technical agreement)
Elongation(%) 0.5%-8%
(according to customer's requirements and technical agreement)
Typical core I.D. Φ76.2 Φ152
Typical Coil O.D. Φ300 Φ500 Φ1000 (selectable)
Trace Elements pb≤0.01 cd≤0.01 As≤0.01
Wettability ≥Class B
Pin no. (P/m²) according to custiomer's requirements and technical agreement
Light (L) according to custiomer's requirements and technical agreement
Coil Connector according to custiomer's requirements and technical agreement
Surface Quality 1 even serface flatness 2 clean surface without corrosion,spots,wrinkles,scratches,light and dark lines,marks slots etc. 3 no light spots,marke,wheel mark and black line. 4 no yellow spots from the lubricatio oil burning and breaks on the surface of the final production.
Quality Outside No defects such as burring, cracks, telescoping, loosen coils, core out, arrow etc.. Welding firmly, foil section neat and clean.

mechanical property:

Temper

Tensile Strength

Rm(MPa)

 Erichsen(mm) Elongation(%)
O 80-110 6.0 20
H22 100-135 5.5 16
H24 115-145 5.0 12
H26 125-160 4.0 8
H18 160 - 1
