Mirror Aluminium Flat Strips Coil In Roll / 5754 H111 Aluminum Sheet Oil Pipe
Mirror Aluminium Flat Strips Coil In Roll / 5754 H111 Aluminum Sheet Oil Pipe
Mirror Aluminium Flat Strips Coil In Roll / 5754 H111 Aluminum Sheet Oil Pipe
Mirror Aluminium Flat Strips Coil In Roll / 5754 H111 Aluminum Sheet Oil Pipe
Mirror Aluminium Flat Strips Coil In Roll / 5754 H111 Aluminum Sheet Oil Pipe
Mirror Aluminium Flat Strips Coil In Roll / 5754 H111 Aluminum Sheet Oil Pipe
Specifications
Brand Name :
Dongchong
Model Number :
1000-8000series
Certification :
ISO,MTC,MSDS,ROHS,REACH,SGS
Place of Origin :
Chongqing ,Dongchong
MOQ :
500-5000kg for different product
Price :
negotiable
Payment Terms :
TT/LC
Supply Ability :
10000 Tons per month
Delivery Time :
2-3days for stock , 7-10days for normal size .25-30days for customized size
Packaging Details :
Wooden pallet , Wooden Box
Application :
Industry, manufacture,electronic communication
Hardness :
H12/22 H14/24 H16/26 H18 H19 H32,H112,H111,O,T4,T6,T5,T651
Material :
DC,CC
Surface :
polish, mirror ,mill finish
color :
Silver,bronze,black,gold,blue,grey,champagne,bright,etc
sample :
provided
delivery date :
3-5days for stock , 7-10 days for normal use, 25-30days for customized
packing :
eye to eye , eye to sky , wooden pallet , wooden box ,paper box
Description

5052 5754 5083 H32 O H34 H38 Aluminum/Aluminium Alloy Flat Strip coil in roll

Product specification

Type

 Aluminium strip

Material

 5000 Series:5005,5025,5040,5052,5056,5083,5A05,5050 etc.
Temper H12, H14, H16, H18, H22, H24, H26 ,H111,H112,O
Specifications Thickness 0.006-200mm or as your required Width :6mm-1200mm or as your required.
Surface Bright, polished,mill finish , mirror
Standard ATSTM B209, JIS H4000-2006,GB/T3190-2008,GB/T3880-2006
Application

1) Kitchenware, food and chemical products processing and storage devices;

2) Aircraft fuel tanks, oil pipe, rivets, wire;

3) Cans cover, car body panels, steering plates, stiffeners, brackets and

other components;

4) Manufacturing trucks, tower building, ship, train, furniture, machinery parts,

precision machining with the tubes, rods, shaped, sheet metal.
Trade Information Packaging Details:Wooden pallet,Wooden box
Delivery Detail:3-5days for stock, 10-15days for normal size,25-30days for customized size
MOQ :500kg-5000kg according to different products
Supply Ability:10000tons per month
Payment terms: TT,LC

ALLOY CHEMICAL COMPOSITION (%)
Si Fe Cu Mn Mg Cr Ni Zn Ti Zr Other Al
5052 0.25 0.4 0.1 0.1 2.2-2.8 0.15-0.35 __ 0.1 __ __ 0.05 0.15 rest
5A06 ≤0.40 0.000～0.400 ≤0.10　 0.50～0.8　 5.8～6.8　 __ 0.0001～0.005　 ≤0.20 0.02～0.10　 __ 0.05 0.1 rest
5005 0.3 0.7 0.2 0.2 0.5-1.1 0.1 __ 0.25 __ __ 0.05 0.15 rest
5050 0.4 0.7 0.2 0.1 1.1-1.8 0.1 __ 0.25 __ __ 0.05 0.15 rest
5154 0.25 0.4 0.1 0.1 3.1-3.9 0.15-0.35 0.25 0.2 0.05 0.15 rest
5754 0.4 0.4 0.1 0.5 2.6-3.6 0.3 __ 0.2 0.15 __ 0.05 0.15 rest
5454 0.25 0.4 0.1 0.5-1.0 2.4-3.0 0.05-0.2 0.25 0.2 0.05 0.15 rest
5182 0.2 0.35 0.15 0.2-0.5 4.0-5.0 0.1 0.25 0.1 0.05 0.15 rest
5083 0.4 0.4 0.1 0.4-1.0 4.0-4.9 0.05-0.25 _ 0.25 0.15 __ 0.05 0.15 rest
5086 0.4 0.5 0.1 0.2-0.7 3.5-4.5 0.05-0.25 0.25 0.15 0.05 0.15 rest

Technical Property

Alloy Temper Thickness(mm) Tensile strength(Mpa) Yeild strength(Mpa) Elongation(%)
Min
5052 H111 O >0. 20 — 0. 50 170 — 215 65 12
>0. 50 — 1. 50 14
>1.55 — 3.00 16
>3. 00 — 6. 00 18
>6.00 — 12. 50 165-215 19
>12. 50 — 50.00 —
H12 >0. 20 — 0. 50 210 — 260 160 4
>0.5-1.5 5
>1.50 —3.00 6
>3, 00 — 6. 00 8
H14 >0. 20 — 0. 50 230-280 180 3
>0.50-1.50 3
>1. 50 -3. 00 4
>3.00 — 6.00 4
H16 >0. 20 — 0, 50 250—300 210 2
>0. 50 — 1. 50 3
>1. 5- 3.0 3
>3.00 — 4. 00 3
H18 >0. 20-0.50 270 240 1
>0. 50 — 1. 50 2
> 1.50 — 3.00 2
H22 H32 >0. 20—0. 50 210 — 260 130 5
>0. 50-1.50 6
>1.50 — 3.00 7
>3. 00 — 6. 00 10
H24 H34 >0. 20 — 0. 50 230 — 280 150 4
>0.50 — 1. 50 5
>1,50 — 3.00 6
>3.00 — 6.00 7
H26 H36 >0. 20 — 0.50 250 — 300 180 3
>0. 50 — 1, 50 4
>1.50—3.00 5
>3. 00—4. 00 6
H38 H28 >0. 20 — 0, 50 270 210 3
>0. 50~1. 5 3
>1. 50 — 3. 00 4
H112 >6.00—12. 50 190 80 7
>12. 50 — 40,00 170 70
>40, 00 — 80, 00 170 70
Alloy Temper Thickness(mm) Tensile strength(Mpa) Yeild strength(Mpa) Elongation(%)
Min
5AO6 O 0.5-4.5 315 155 16
H112 ＞4.5-10 315 155 16
＞10-12.5 305 145 12
＞12.5-25 305 145 —
＞25-50 295 135 —
5082 H18 H38 ＞0.2-0.5 335 1 1
H19 H39 ＞0.2-0.5 355 1
5005 O H111 ＞0.20 — 0. 50 100—145 35 15
＞0. 50〜1.50 19
＞1.50 — 3. 00 20
>3, 00 — 6, 00 22
>6.0-12.5 24
>12.5-50
H12 >0.20 — 0. 50 125-165 95 2
＞0. 50〜1.50 2
>1.50 — 3. 00 4
>3, 00 — 6, 00 5
H22 H32 >0.20 — 0.50 125 — 165 80 4
>0. 50〜1. 50 5
>1. 50 — 3.00 6
>3.00 — 6.00 8
H24 H34 >0. 20 — 0.50 145 — 185 110 3
>0.50—1. 50 4
>1, 50—3, 00 5
>3. 00 — 6. 00 6
H26 H36 >0.20 — 0. 50 165 — 205 135 2
>0. 50—1.50 3
>1.50 — 3.00 4
>3.00 — 4.00 4
H28 H38 >0. 20 — 0.50 185 160 1
>0.50 — 1.50 2
>1.50 — 3.00 3
H112 >6, 00 —12. 50 115 —— —
>12. 50 — 40. 00 105 —
>40.00 — 80. 00 100 —
