Specifications
Brand Name :
Dongchong
Model Number :
1050
Certification :
ISO,MTC,MSDS,ROHS,REACH,SGS
Place of Origin :
Chongqing, China
MOQ :
500-5000kg for different product
Price :
negotiable
Payment Terms :
TT/LC
Supply Ability :
10000 Tons per month
Delivery Time :
5-10 working days for stock , 10-30 working days for customization.
Packaging Details :
Wooden pallet , Wooden Box
Thickness :
0.2-6mm
Alloy :
1050
Width :
100-1500mm
Length :
in coils or customized
Surface finish :
coated with PVDF / PE/ powder
Temper :
H**
Application :
construction material,roofing material.
Standard :
GB/T 3880.2-2012, GB/T 3190-2008
Description

Color Coated Aluminium Sheet Aluminum Alloy Sheet Coil For Gutters

Product specification:

1. Alloy: 1050

2. Temper: H**

3. Thickness: 0.2-6mm

4. Width: 100-1500mm

5. Length: in coils or customized

6. Surface finish: coated with PVDF / PE / powder

7. Application: construction material,roofing material.

8. Standard: ISO,FDA,SGS,Reach,RoHS,MSDS,SVHC

Alloy 1060 chemical component:
Si: 0.25 Fe: 0.4 Cu: 0.05 Mn: 0.05 Mg: 0.05 Cr: - Ni: -
Zn: 0.05 Ti: 0.03 Zr: - Other Total: 0.03 Al: 99.5%

Application industry or fields:

  • Interior decorating
  • Ceiling material
  • Furniture,cabinets
  • Elevators walls
  • Traffic signs’ board
  • Nameplates, license plates
  • Automotive interior and exterior panels
  • Photo frame
  • Refrigerators
  • Microwave ovens
  • Audio equipment
  • Aerospace
  • Military products
  • Train/metro products
  • Mould base plate
  • Mechanical parts
  • Thermal insulation material
  • Marine grade plate for vessel or ship
  • For roofing sheet
  • For buiding material
  • Solar reflective panel
  • Out wall for building appearance
Alloy series Alloy code Typical application
1000 1050 CTP,cosmetic cap stock,cap stock,aluminum circle stock,ACP stock,tread plate,specular sheet,cabinet sheet,capacitor shell stock,lighting,component stock,capacitor foil,foil stock/production,chemical equipment,food industry containers,architectural flashings,cable,sheathing,heat sink module,fin stock,name plates,utensils,spun hollowware,rivets,high conductivity applications, ferrules.
1060
1070
1080
1100
1145
1200
1235
1350

Usage and application: 1)Interior decorating 2)Ceiling material 3)Furniture,cabinets 4)Elevators walls

5)Traffic signs’ board 6)Nameplates, license plates 7)Automotive interior and exterior panels 8)Photo

frame 9)Refrigerators 10)Microwave ovens 11)Audio equipment 12)Aerospace 13)Military products

14)Train/metro products 15)Mould base plate 16)Mechanical parts 17)Thermal insulation material

18)Marine grade plate for vessel or ship 19)For roofing sheet 20)For buiding material 21)Solar

reflective panel 21)Out wall for building appearance

Part of our stock list:

Material code Standard Alloy Temper Dimension N.W.(KG) QTY
187H51130016 EN485 1050A H24 3*1500*3000 500 14
185E151300203 EN485 1050A H24 0.8*1000*2000 566 133
186H53130003 EN485 1050A H24 2*1500*3000 990 42
186H53130009 EN485 1050A H24 2*1500*3000 990 42
186H53130004 EN485 1050A H24 2*1500*3000 990 42
186H53130005 EN485 1050A H24 2*1500*3000 990 42
185F31110005 EN485 1050A H24 1*1250*2500 1002 122
185F31110003 EN485 1050A H24 1*1250*2500 1002 122
185F31110004 EN485 1050A H24 1*1250*2500 1002 122
185F31110010 EN485 1050A H24 1*1250*2500 1002 122
185F31110007 EN485 1050A H24 1*1250*2500 1002 122
185F31110008 EN485 1050A H24 1*1250*2500 1002 122
185F31110009 EN485 1050A H24 1*1250*2500 1002 122
185F31110011 EN485 1050A H24 1*1250*2500 1002 122
185F31110012 EN485 1050A H24 1*1250*2500 1002 122
185F31120007 EN485 1050A H24 1.5*1000*2000 978 123
185F31120009 EN485 1050A H24 1.5*1000*2000 978 123
185F31120010 EN485 1050A H24 1.5*1000*2000 970 122

About us:

We specialize in aluminum products, such as aluminium alloy plate - aluminium alloy sheet - aluminium

alloy foil - aluminium alloy tube and pipe - aluminium alloy rod and bar - aluminium alloy perforated

engraved bended wall panel and ceiling panel - aluminium alloy cutting pieces etc., gained various

certificates to ensure our product quality and service. We offer ODM and OEM service, welcome to

inquire for your customization.

Our advantages:

  • more than 17-year experience in aluminium industry;
  • well experienced working team, advanced production machines;
  • flexible customization per customers' requirement;
  • prompt cost calculating and price quotation;
  • fast delivery on the basis of quality goods.
