3003 Aluminium Alloy Plate 0.1 Mm - 300 Mm Thickness With Bare Plate Finished
3003 Aluminium Alloy Plate 0.1 Mm - 300 Mm Thickness With Bare Plate Finished
3003 Aluminium Alloy Plate 0.1 Mm - 300 Mm Thickness With Bare Plate Finished
3003 Aluminium Alloy Plate 0.1 Mm - 300 Mm Thickness With Bare Plate Finished
Specifications
Brand Name :
RUIYI
Model Number :
3003 H14
Certification :
ISO 9001
Place of Origin :
China
MOQ :
5 Ton
Price :
US$2300 - US$3300 Per Ton
Supply Ability :
1000 Ton per month
Delivery Time :
30 working days
Packaging Details :
plywood pallets
Alloy name :
3003 H14 Bare aluminum plate alloy
Temper :
H22, H24, H14
Thickness :
0.1 mm - 300 mm
Width :
30 mm - 2300 mm
Finish :
Bare plate
Product treatment :
CC or DC
Standard :
3003 GB/T 3190-1996
Description

3003 H14 aluminium alloy plate bare Aluminum Sheet 3003 H14 manufacturer

Aluminum alloy plate Sheet 3003 H14 Bare is an excellent choice for chemical equipment and general sheet metal projects due to its superior corrosion resistance and good workability. Aluminum 3003 H14 bare sheet works well in fabrication and decorative architectural uses because it is highly workable, formable, and weldable, while being capable of withstanding outdoor weather

Alloy 3003 is fairly low strength but it can be hardened to a significant degree by cold working, enabling a series of “H” tempers. Alloy 3003 is also produced as a bright finish treadplate (also known as chequer plate) with industrial and decorative applications.

3003-H14 Aluminum alloy plate is alloyed with 1.20% manganese, which increases the strength of 3003 over commercially pure aluminum (1100 series).3003 has excellent workability, weldability, and good corrosion resistance

3003 Aluminum is one of the most widely used of all aluminum alloys. It is a general purpose aluminum, with moderate strength, good workability and weldability, and excellent corrosion resistance. 3003 is a non heat treatable grade, and it may be deep drawn, or spun, welded, or brazed.

Alloy Available: 1050 1060 1100 3003, 3105, 5052, 5005, 5754 5083 5182, 6061 6063 6082, 7075, 8011…
Temper: HO, H111,H12, H14, H24,H 32, H112, T4, T6, T5,T651
Surface:Mill/Emboss/Diamond/2bar/3bars/Bright
Thickness: 0.2mm to 300mm
Width: 30mm to 2300mm
Length:1000mm to 10000mm.

Aluminum stair tread sheet, Aluminum tread Brite plate,Aluminum checker plate manufacturers, Perforated aluminum sheet china,Diamond sheet manufacturers, Aluminum tread plate manufacturers

3003 Aluminium Alloy Plate 0.1 Mm - 300 Mm Thickness With Bare Plate Finished

Chemical Analysis of aluminum alloy Plate
Alloy Si Fe Cu Mn Mg Cr Ni Zn Ti Al
1050 0.25 0.4 0.05 0.05 0.05 - - 0.05 0.03 Remains
1060 0.25 0.35 0.05 0.03 - - - - - Remains
1070 0.2 0.25 0.04 0.03 0.03 - - - - Remains
1100 0.95 0.95 0.05-0.2 0.05 - - 0.1 - - Remains
1200 1 1 0.05 0.05 - - - 0.1 0.05 Remains
3003 0.6 0.7 0.05-0.2 1.0-1.5 - - - 0.1 - Remains
5005 0.3 0.7 0.2 0.2 0.5-1.1 0.1 - 0.25 - Remains
5042 0.2 0.35 0.15 0.2--.5 3.0-4.0 0.1 - 0.25 0.1 Remains
5052 0.25 0.4 0.1 0.1 2.2-2.8 0.15-0.35 - 0.1 - Remains
5083 0.4 0.4 0.1 0.4-1.0 4.0-4.9 0.05-0.25 - 0.25 - Remains
5754 0.4 0.4 0.1 0.5 2.6-3.6 0.3 - 0.2 - Remains
6061 0.4-0.8 0.7 0.15-0.4 0.15 0.8-1.2 0.04-0.35 - 0.25 - Remains
6063 0.2-0.6 0.35 0.1 0.1 0.45 0.1 - 0.1 - Remains
6082 0.7-1.3 0.5 0.1 0.4-1.0 0.6-1.2 0.25 - 0.2 - Remains
7050 0.12 0.15 2.0-2.6 0.1 1.9-2.6 0.04 - 5.7-6.7 0.06 Remains
7075 0.4 0.5 1.2-2.0 0.3 2.1-2.9 0.18-0.28 - 5.1-6.1 0.2 Remains
