5052 3003 Aluminium Chequered Plate Fire Resistance Leaf Pattern For Solar Reflective Film
5052 3003 Aluminium Chequered Plate Fire Resistance Leaf Pattern For Solar Reflective Film
5052 3003 Aluminium Chequered Plate Fire Resistance Leaf Pattern For Solar Reflective Film
5052 3003 Aluminium Chequered Plate Fire Resistance Leaf Pattern For Solar Reflective Film
Specifications
Brand Name :
RUIYI
Model Number :
5052 3003
Certification :
ISO9001
Place of Origin :
China
MOQ :
5 Ton
Price :
US$2100- US$3500 per ton
Supply Ability :
1000 Ton Per Month
Delivery Time :
25 working days
Packaging Details :
wooden pallets
Product name :
3003 aluminum sheet
Alloy Grade :
5052, 3003
Temper :
H116, H32, H22
Features :
Anti-skid
Thickness :
1.2 mm -7.0mm or custom
Width :
100 MM - 1650MM
Finish :
Mill or Brite
Pattern :
Checkered or Chequered
ASTM Standard :
ASTM B209-10
Description

5052 3003 Quality Leaf Pattern Aluminium Chequered Plate sheet Fire Resistance For Solar Reflective Film

ISO Certified supplier and exporter of Aluminium Alloy Sheets Plates, Aluminum Chequered PlatesSupplier, Buy ASTM B209 6061 / 5052 Aluminium Diamond

0.020" 5052-H32 Bare Aluminum Sheet is commonly used for the bodies of boats, buses, trucks, utensils, mail boxes and trailers, as well as for chemical drums. It is nonmagnetic and not heat treatable.

5052 aluminum plate offers high corrosion resistance and salt water resistance, making it popular for marine applications

5052 - H32 Sheet and Treadplate. Aluminium alloy 5052 in H32 temper has very good corrosion resistance to seawater and marine and industrial atmosphere.

5052 Aluminum Sheet. 5052 is alloyed with 2.5% magnesium. Tensile strength range is 31 to 44 KSI. 5052 has excellent workability, weldability and corrosion resisitance.

Aluminum Checkered Plates offered by us have high ductility and can be easily molded to transform the sheet metal into different shapes to be used for a large variety of finished parts. The sheets available with us find its wide application in various industry segments such as food processing for making cans, automobiles for making different products. We deliver Aluminum Plate grade 53000 / 5086 and also in many different grades like 6082 , 6061, 6063, 2014 , 5052 etc.

We can supply
Alloy: 1050 1060 1100 3003, 3105, 5052, 5005, 5754 5083 5182, 5086, 6061 6063 6082, 7075, 8011…
Temper: HO, H111,H12, H14, H24,H 32, H112, T4, T6, T5,T651
Surface:Mill/Emboss/Diamond/2bar/3bars/Bright
Thickness: 0.2mm to 300mm
Width: 30mm to 2300mm
Length:1000mm to 10000mm.

aluminum stair tread sheet, Aluminum tread Brite plate,Aluminum checker plate manufacturers, Perforated aluminum sheet china,Diamond sheet manufacturers, Aluminum tread plate manufacturers, Aluminium sheet factory, aluminium plate metal

5052 3003 Aluminium Chequered Plate Fire Resistance Leaf Pattern For Solar Reflective Film

Chemical Analysis of aluminum alloy Plate
Alloy Si Fe Cu Mn Mg Cr Ni Zn Ti Al
1050 0.25 0.4 0.05 0.05 0.05 - - 0.05 0.03 Remains
1060 0.25 0.35 0.05 0.03 - - - - - Remains
1070 0.2 0.25 0.04 0.03 0.03 - - - - Remains
1100 0.95 0.95 0.05-0.2 0.05 - - 0.1 - - Remains
1200 1 1 0.05 0.05 - - - 0.1 0.05 Remains
3003 0.6 0.7 0.05-0.2 1.0-1.5 - - - 0.1 - Remains
5005 0.3 0.7 0.2 0.2 0.5-1.1 0.1 - 0.25 - Remains
5042 0.2 0.35 0.15 0.2--.5 3.0-4.0 0.1 - 0.25 0.1 Remains
5052 0.25 0.4 0.1 0.1 2.2-2.8 0.15-0.35 - 0.1 - Remains
5083 0.4 0.4 0.1 0.4-1.0 4.0-4.9 0.05-0.25 - 0.25 - Remains
5754 0.4 0.4 0.1 0.5 2.6-3.6 0.3 - 0.2 - Remains
6061 0.4-0.8 0.7 0.15-0.4 0.15 0.8-1.2 0.04-0.35 - 0.25 - Remains
6063 0.2-0.6 0.35 0.1 0.1 0.45 0.1 - 0.1 - Remains
6082 0.7-1.3 0.5 0.1 0.4-1.0 0.6-1.2 0.25 - 0.2 - Remains
7050 0.12 0.15 2.0-2.6 0.1 1.9-2.6 0.04 - 5.7-6.7 0.06 Remains
7075 0.4 0.5 1.2-2.0 0.3 2.1-2.9 0.18-0.28 - 5.1-6.1 0.2 Remains
