12mm Thickness Tempered Glass Demountable Partition Walls STC 48Db
12mm Thickness Tempered Glass Demountable Partition Walls STC 48Db
12mm Thickness Tempered Glass Demountable Partition Walls STC 48Db
12mm Thickness Tempered Glass Demountable Partition Walls STC 48Db
12mm Thickness Tempered Glass Demountable Partition Walls STC 48Db
12mm Thickness Tempered Glass Demountable Partition Walls STC 48Db
12mm Thickness Tempered Glass Demountable Partition Walls STC 48Db
12mm Thickness Tempered Glass Demountable Partition Walls STC 48Db
Specifications
Brand Name :
APRO
Model Number :
12161000
Certification :
AAMA,AS2047,ISO9001
Place of Origin :
Guangzhou,China
MOQ :
10 square meters
Price :
negotiation
Payment Terms :
D/A, L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000 suqare meters per month
Delivery Time :
30-40 days for 10-100 square meter , if more than 100 square meter,need to be negotiated foam layer and hard cardboard which is suitable for container shipping.
Packaging Details :
foam layer and hard cardboard which is suitable for container shipping.
Material :
Glass
Description

12mm thickness tempered glass aluminum frame demountable partition walls for office glass partition wall

When the architecture of a building promotes lightness and space and the function of the room requires a minimalist partition solution, frameless series glass partition system provides the answer.

With the glazing held in a perimeter frame with no need for vertical aluminum framing, a transparent and open room is created. Aluminum profiles with powder coated or anodized finishes are serving as horizontal and vertical connections to the building structure, glass and glass joint by special adhesive.
1) Clean lines and visual transparency
2) Flush single or double glazing
3) Frameless structural glazing construction method
4) Glass and glass joint by special adhesive
5) Wall thickness 108 mm, flush with solid wall and door elements
6) Venetian blinds can be centrally integrated in double-glazing cavity
7) Adjustable accessories in base frame for leveling allowance
8) Sound insulation test certificates for glass wall STC up to 48 dB
12mm Thickness Tempered Glass Demountable Partition Walls STC 48Db
Design features
Frameless panoramic partition system
Series
108 series frameless glass partition
Layers
Single/double glass
Glass thickness
12mm
Application
Office and conference room
Panel thickness
108mm
Built-in doors
Single glass and double glazed doors, solid doors
View
Transparent, colored or frosted glass, blinds intergrated between the glass panels
Noise reduction coefficient
STC 48 db
Door Accessories
Electronic lock available

12mm Thickness Tempered Glass Demountable Partition Walls STC 48Db

Product Details
Aluminium Profiles
Aluminium Alloy
ALU Wall Thickness
Surface Finishing and Color
6063-T5
1.2mm--2.0mm, Normally 1.4mm for window, 2.0mm for door
Anodized, Sliver & Bronze
Powder Coating, colore should be confirm with buyer
Electrophoresis, Sliver& Champagne
PVDF
With thermal break aluminium system design for more energy saving function
Glass
Type
Thickness
Color
Float glass
Single: 4mm -12mm, Double Glazing (With 6A/9A/12A/27A space)
clear/super clear/ tinted blue/green/coffee brown/grey
Insulated double glass
Insulated triple glass
Reflective glass
Low-E glass
Tempered glass
Laminated glass
Customized art glass
Hardware
High quality, made in China of well-know brand (Kinlong )/ made in Germany (Siegenia /Roto )
Accessories
Use EPDM sealant rubber
Stainless steel 304# accessories.
Production standard
Basis on the shop drawings which approved by the buyer

12mm Thickness Tempered Glass Demountable Partition Walls STC 48Db
