Various Colour Coated Aluminum Coil / Aluminium Composite Sheet 5000 Kg
Various Colour Coated Aluminum Coil / Aluminium Composite Sheet 5000 Kg
Various Colour Coated Aluminum Coil / Aluminium Composite Sheet 5000 Kg
Various Colour Coated Aluminum Coil / Aluminium Composite Sheet 5000 Kg
Specifications
Brand Name :
Trumony
Model Number :
TR-1000
Certification :
ISO9001-2008
Place of Origin :
China
MOQ :
5 Ton
Price :
Negotiation
Supply Ability :
800,000 Per Year
Delivery Time :
30 Working days
Packaging Details :
Standard Export Packages
Alloy :
1000 series , 3000 series , 5000 series
Temper :
H44 , H46 , H48
Thickness :
0.2 ~ 1.5 mm
Front Side :
PE , Alu Eciling Face - Paint , PVDF
Back Side :
Mill Finish
Description

Colorful Aluminium Color Coated Coil For Ceilings Usage

Quick Details ;

1 , Products : Aluminum Color Coated Coil & Sheets

2 , Alloy : 1000 series , 3000 Series , 5000 series

3 , Aluminum Thickness (mm) : 0.2 ~ 1.5 mm

4 , Temper : H44 , H46 , H48 ,

5 , Dry Coating Thickness : Top Coating : 8 ~ 22 um ; Pros and cons single bottom coating : 7 ~ 20

6 , Width : 700 ~ 1600 mm

7 , Coil wight : < / = 5000 kg

8 , I D : 405 mm , 505 mm

Remarks : 1 . The alloy , temper & size can be negotiated by buyer and seller

2 , Width can be 50 ~ 800mm as per customer's requirement.

Coating Characteristic Table

Inspection items Coating Types
PVDF PE Ceiling Top Lacquer
No natural clear lacquer With natural clear lacquer
Coating Thickness 26 + /-1 18 + / - 1 20 + / - 1
Glossy Tolerance 60O glossy value ≥ 80 unit , tolerance + / - 10 unit glossy value ≥ 80 unit , tolerance + / - 10unit
60O glossy value ≥ 20 ~ 80 unit , tolerance + / - 7 unit glossy value≥20 ~ 80 unit , tolerance + / - 7 unit
60O glossy value >20 unit , tolerance + / - 5unit 60O glossy value >20 unit , tolerance + / - 5unit
Pencil Hardness ≥ IH ≥ 2H ≥2H
Flexible ≤2T ≤3T ≤2T
Impact Resistance No failing , No crack No failing , No crack
Adhesive Quality 0 grade and 1 grade 0 grade and 1 grade
Acid Resistance No Change Coating no change
Alkalistability No change -
Solventresistance Bottom not appearance after 100 times Bottom not appearance after 100 times Bottom not appearance after 100 times Bottom not appearance after 100 times
Color Difference The coating color is almost same as confirmed by buyer and seller , the color difference tested by colorimeter between single coating and sample is less tan 1.2 , same lot products color difference

Introduction of Products

Aluminum Color Coated Coil produced by nice coated equipment, advantaged technology , coated by various color and different thickness , appearance colorful and shining products.

The products mainly used to produce aluminum composite panels , aluminum single sheet, aluminum beehive sheets, veined coating aluminum coil and mainly used in aluminum rooler shutter and roller blinds , aluminum ceiling , aluminum door and widows, scan sign , decorating car , boat , aluminum container, home appliances , kitchen ware and cabinet, control panel , light - fixture , furniture sun power reflector panel and so on .

Characteristics

Cood Weathering : Choosing different coating materials as per using environment, the coating is hardness and slick , ater - resistance , sovle - resistance , anti-washing , long ages, Especially for PVDF materials , it has good weather resistance to use for decorating wall and special place for more than 20 years under bad whether .

Colorful : Different materials and color appearances top grade floweriness .

Recycling : it can be recycling , no depreciation , high.

Saving energy : aluminum is containing electric and energy itself , 95 % can be recycled used, less depreciation.

Order Procedure

Color Comfirmation

Customer provides sample or color card and code -- Painter matches the color as per the sample -- Coating and getting sampl -- Customer confirms the sample

Mill Finish Aluminum Coil comfirmation

Customer provides technical standard --- Technology confirms to meet the technical requirement

Above two confirmed , arranging production as per order
