Blister Pharma Aluminium Packaging Foil , Cold Resistance Aluminum Foil Safety
Blister Pharma Aluminium Packaging Foil , Cold Resistance Aluminum Foil Safety
Blister Pharma Aluminium Packaging Foil , Cold Resistance Aluminum Foil Safety
Blister Pharma Aluminium Packaging Foil , Cold Resistance Aluminum Foil Safety
Specifications
Brand Name :
Trumony
Model Number :
TR-F141
Certification :
ISO9001-2008 , SGS
Place of Origin :
China
MOQ :
5 metric tons
Price :
negotiation
Payment Terms :
T/T or LC
Supply Ability :
40,000 mt per year
Delivery Time :
40 working days after received your down payment
Packaging Details :
Standard export packaging
Alloy :
8079 , 8011 and etc.
Temper :
HO , H18 and etc.
Thickness :
0.018 - 0.030mm
Width :
150 - 1850mm
I. D. :
76mm , 152mm
Normal O. D. :
400 - 600mmm
Pin hole :
According to GB/T3198-2010
Other Requirements :
Other sizes and specifications are available according to customer's request
Description

25mic x 860mm 8011 O Aluminum Blister Pharma Packaging Foil for Medicine

1. Our chemical composition:

Alloy

 Si Fe Cu Mn Mg Zn Cr Ti code
8011 0.5-0.9 0.6-1.0 0.1 0.2 0.05 0.1 0.05 0.08 1
1235 Si+Fe:0.65 0.05 0.05 0.05 － － 0.06 2
8079 0.05-0.3 0.7-1.3 0.05 － － 0.1 － 3

2. Our mechanical property:

Foil Classification Thickness(mm)
Alloy		 Thickness Tolerrance Width Tolerance
Thin Gauge
0.018-0.030		 0.018

1235

8011

8079

 ±5% (200-1880)±1
0.019
0.020
0.025
0.027
0.030

Mechanical Performance		 Strengthen(Mpa) 50-160
(according to customer's requirements and technical agreement)
Elongation(%) 0.5%-8%
(according to customer's requirements and technical agreement)
Typical core I.D. Φ76.2 Φ152
Typical Coil O.D. Φ300 Φ500 Φ1000 (selectable)
Trace Elements pb≤0.01 cd≤0.01 As≤0.01
Wettability ≥Class B
Pin no. (P/m²) according to custiomer's requirements and technical agreement
Light (L) according to custiomer's requirements and technical agreement
Coil Connector according to custiomer's requirements and technical agreement
Surface Quality 1 even serface flatness 2 clean surface without corrosion,spots,wrinkles,scratches,light and dark lines,marks slots etc. 3 no light spots,marke,wheel mark and black line. 4 no yellow spots from the lubricatio oil burning and breaks on the surface of the final production.
Quality Outside No defects such as burring, cracks, telescoping, loosen coils, core out, arrow etc.. Welding firmly, foil section neat and clean.

3. Our advantages

(1) We have rich experience in this industry in China from 2004;

(2) Good reputation in packaging foil areas;

(3) We have our own R&D for new material research;

(4) We start our productions from aluminum ingot , so we can control the whole processing as well;(5) With Certificate ISO9001-2008;

(6) Excellent experience and cooperation with big client in the world;

(7) Fast delivery;

(8) High performance cost ratio;

(9) Customized orders are available;

(10) Good communication skills, good service and understandings for customers.

4. Features

(1) Suitable for refreshment ; biscuit ; candy ; milk powder ; instant drink and pet food bag , etc;

(2) Environmentally-friendly heat insulation material;

(3) Easy for printing and laminating;

(4) Perfect oxygen and steam barrier;

(5) Moisture proof; protect from light ; gas barrier, non-breakage; non leakage;

(6) Heat Insulation Facing with high tensile strength and bursting strength;

(7) Our plain foils can be manufactured according to customer's requirements;

(8) Good stretching resistance in length and breadth.

5. Application

Our Flexible Packaging Foil can be used to laminate with other materials including PVC or PET to make long life packs or aseptic packaging for drinks and dairy products which enable storage without refrigeration; Aluminum foil is laminated to used for packing many other oxygen or moisture sensitive foods; in the form of pouches; sachets, etc;
