Specifications
Brand Name :
Trumony
Model Number :
5182
Place of Origin :
China
MOQ :
5 tons
Supply Ability :
100000 ton/year
Delivery Time :
30days
Packaging Details :
Fumigated wooden pallet specialized for export
Synonym :
Aluminum Alloy Sheet
Alloy :
5182
Temper :
H111
Thickness :
0.15-600mm
Width :
20-2650mm
Length :
500-16000mm
Description

5182 Extra Long Aluminum Alloy Plate For Oil Tanker / Trailer

1. Product description:
Aluminum 5xxx series alloy(5182 5083 5754 5154 5454) has high corrosion resistance and good forming property.

Temper:H321/H111/H32/H22

2. Application:decoration,automobile,oil tanker,trailer,marine service etc.

3. Our advantage:We could supply the aluminum plate width above 2000mm.

4. Package:Export wooden pallets or wooden case with seaworthy packing or as customer 's requirements.

5. Chemical composition:

ALLOY NO. Si Fe Cu Mn Mg Cr Zn Ti OTHER AL
1050 0.25 0.4 0.05 0.05 0.05 0.05 0.03 0.03 ≥99.5
1060 0.25 0.35 0,05 0.03 0.03 0.05 0.03 0.03 ≥99.6
1070 0.2 0.25 0.04 0.03 0.03 0.04 0.03 0.02 ≥99.7
1100 0.95(Si+Fe) 0.05-0.20 0.05 0.1 0.05 ≥99
3003 0.6 0.7 0.05-0.2 1.0-1.5 0.1 0.05 Remainder
3004 0.3 0.7 0.25 1.0-1.5 0.8-1.3 0.25 0.05 Remainder
3005 0.6 0.7 0.3 1.0-1.5 0.2-0.6 0.1 0.25 0.1 0.05 Remainder
3104 0.6 0.8 0.05-0.25 0.8-1.4 0.8-1.3 0.25 0.1 0.05 Remainder
4047 11.0-13.0 0.8 0.3 0.15 0.1 0.2 Remainder
5052 0.25 0.4 0.1 0.1 2.2-2.8 0.15-0.35 0.1 Remainder
5252 0.08 0.1 0.1 0.1 2.2-2.8 0.05 Remainder
5754 0.4 0.4 0.1 0.5 2.6-3.6 0.3 0.2 0.15 Remainder
5083 0.4 0.4 0.1 0.4-1.0 4.0-4.9 0.05-0.25 0.25 0.15 Remainder
5182 0.2 0.35 0.15 0.2-0.5 4.0-5.0 0.1 0.25 0.1
6061 0.4-0,8 0.7 0.15-0.4 0.15 0.8-1.2 0.04-0.35 0.25 0.15 Remainder
6063 0.2-0.6 0.35 0.1 0.1 0.45-0.9 0.1 0.1 0.1 Remainder
6082 0.7-1.3 0.5 0.1 0.4-1.0 0.6-1.2 0.25 0.2 0.15 Remainder
7075 0.4 0.5 1.2-2.0 0.3 2.1-2.9 0.18-0.28 5.1-6.1 0.2 Remainder

6. Technical parameter

Typical alloy: 5182
Temper:

H111,H112,H114,H116,H321

O,H12,H14
Thickness(mm): 0.15-600mm
Width(mm): 20-2650mm
Length(mm): 500-16000mm
Application: The outer plate, deck, refrigeration device, tanker, oxygen Generator tower body of the ship's side ship Bottom

7.Application in the market:

5182 Aluminum Alloy Plate is mainly used for low-load parts that require high plasticity and good weldability, working in liquid or gaseous media, such as fuel tanks, gasoline or lubricant catheters, various liquid containers and other small load parts made with deep pull: wire is used to make rivets. Thin plate can be used to process canister cover, car body plate, control plate, reinforcement parts, bracket and other parts.

8.Product features:

Etra long width

Good anti-corrosion and formability,
Small elastic modules
Easy to welding
Easy processing
Without low temperature brittleness as well as non-magnetic
Moderate strength

9.Terms and conditions:

Trade term:CIF / CFR / FOB
Payment term:30% before production+70% before shipment;or 100% Irrevocable L/C at sight;Or we can further cummunicate with each other about this part.
Shipment:Normally it is about 30-35days
MOQ:5 metric tons for each thickness. (Normally it is formed according to the concrete specifications.)
Quantity tolerance:+/-10% of total quantity as confirmed PI.
