4343 / 3003 / 7072 Hf Welded Aluminum Tube For Car Radiator
4343 / 3003 / 7072 Hf Welded Aluminum Tube For Car Radiator
4343 / 3003 / 7072 Hf Welded Aluminum Tube For Car Radiator
4343 / 3003 / 7072 Hf Welded Aluminum Tube For Car Radiator
Specifications
Brand Name :
Trumony
Model Number :
TR-CY066
Certification :
ISO9001, ISO14000
Place of Origin :
China
MOQ :
500KG
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
100000ton/Every Year
Delivery Time :
30days including tooling time
Packaging Details :
Export Standard Packing
Type :
4343/3003/7072 Hf Welded Aluminum Tube for Car Radiator
Keyword :
Aluminum Tube for Car Radiator
Technical :
HF process
Alloy :
3003/4343/7072, 4343/3005/7072
Application :
Radiator,condenser, evaporator,water tank
Tube size :
Stock size
Wall thickness :
0.2.0.22.0.23
Surface :
Milled finished
Description

4343/3003/7072 Hf Welded Aluminum Tube for Car Radiator

Specification:

Aluminum Brazing Pipe,Aluminum High Frequency Welding Pipe,Aluminum Mirco-channel Tube,Aluminum Manifold Tube,Aluminum Cold Drawn Pipe,Aluminum Fiber Pipe etc.

1.Application:
Radiator for vehicle&car&off-road widely use this kind of HF B-Type Tube.

2.Alloy states:
Raw material: as request,general material:
4343/3003/4343;4343/3005/4343

3.Thickness Range:
0.22-0.3mm

4.Common Tube Specification:

No. Description Specification(W*H*T)mm Specification(W*H*T)mm Specification(W*H*T)mm
1 HF B-Type Tube 16*2.0*0.22 16*2.0*0.25
2 HF B-Type Tube 22*2.0*0.23 22*2.0*0.25
3 HF B-Type Tube 26*2.0*0.23 26*2.0*0.25 26*2.0*0.26
4 HF B-Type Tube 32*2.0*0.23 32*2.0*0.25 32*2.0*0.3
5 HF B-Type Tube 40*2.0*0.35
6 HF B-Type Tube 52*1.8*0.35 52*1.8*0.4
7 Dimple HF B-Type Tube 56*1.6*0.30

5.Commercial terms

Minimum Order Quantity: 5 metric tons
Price: negotiation
Payment Terms: T/T or LC
Supply Ability: 50,000 mt per year
Delivery Time: 30 working days after received your down payment
Packaging Details: Standard export packaging

4343 / 3003 / 7072 Hf Welded Aluminum Tube For Car Radiator

4343 / 3003 / 7072 Hf Welded Aluminum Tube For Car Radiator
