Aluminium Frame Profile with PVC Strip for Air Conditioning Accessory Unit Assembly
Aluminium Frame Profile with PVC Strip for Air Conditioning Accessory Unit Assembly
Aluminium Frame Profile with PVC Strip for Air Conditioning Accessory Unit Assembly
Aluminium Frame Profile with PVC Strip for Air Conditioning Accessory Unit Assembly
Specifications
Brand Name :
KaiLun
Model Number :
KL-K22082
Certification :
ISO/TS16949,SGS,ROHS...
Place of Origin :
Zhenjiang,Jiangsu China
MOQ :
1 Tons
Price :
Negotiation
Payment Terms :
T/T, L/C...
Supply Ability :
3000Tons / Month
Delivery Time :
Within 12 days after received your deposit
Packaging Details :
EP paper + Kraft Paper + Plywood pallet, as per export packing standard, custom packaging is available
Product Name :
Aluminum Frame Profile
Usage: :
for Air Conditioning Unit
Shape: :
Angle
Grade :
Alumnium Alloy
Key words :
HVAC System
Thickness :
1.4mm
Description

Aluminium Angle Frame Profile with PVC Strip for Air Conditioning Accessory Unit Assembly

Detailed Product Description:

Product Name:

Aluminum Profile for AHU

Alloy:

6005, 6063, 6061, etc.



Application :



for Air Conditioning Accessory Unit Assembly


Surface Treatment:

Mill Finished, Anodizing, Electrophoresis,
Powder Coating, Polishing, Wooden grain,Sand blasting
Size: 41.9*41.9mm Weight: 0.423kg/m

Deep Process :

Milling, Drilling ,Bending, Cutting

Temper:

T5

Primary Technical Data:

1) Chemical composition

Alloy

Si

Mg

Fe

Cu

Mn

Zn

Cr

Ti

6063

0.2~0.6

0.45~0.90

<0.35

<0.10

<0.10

<0.10

<0.10

<0.10

6060

0.3~0.6

0.35~0.60

0.1~0.3

~

<0.10

<0.15

<0.05

~

6463

0.2~0.6

0.45~0.90

<0.15

<0.20

<0.05

<0.05

~

~

6005

0.6~0.9

0.40~0.60

<0.35

<0.10

<0.10

<0.10

<0.10

<0.10

6061

0.4~0.8

0.80~1.2

<0.70

0.15~0.4

<0.15

<0.25

0.04~0.35

<0.15

6082

0.7~1.3

0.60~1.2

<0.50

<0.1

0.4~1.0

<0.20

<0.25

<0.10

6351

0.7~1.3

0.40~0.8

<0.50

<0.1

0.4~0.8

<0.20

~

<0.10


2) Mechanical property

Alloy

Temper

Tensile strength

Yield strength

Elongation

6063

T5

≥ 160Mpa

≥ 110Mpa

≥ 8%

T6

≥ 205Mpa

≥ 180Mpa

≥ 8%

6061

T5

≥ 265Mpa

≥ 245Mpa

≥ 8%


Crossing Sectional Profile:


Advantages of our extrusion process :

The extrusion process provides virtually unlimited opportunities for aluminium product shapes. Costs are cut by designing fewer components, which reduce fabrication and simplify assembly.
These features and benefits are unmatched by other materials and processes:
(1) Complex integral shapes
(2) Cost effective
(3) Low tooling costs
(4) Design flexibility
(5) Versatility in joining
(6) Machinable
(7) Rapid prototyping
(8) Short lead times
